Raspberry Pi AI HAT+ 2
A powerful and versatile machine learning HAT for the Pi 5 - run LLMs, VLMs and conventional vision models on low-power, edge hardware.
In stock, ships same business day if ordered before 2PM
Fastest delivery: Tomorrow*
Disclaimer:
For next-day delivery, the shipping address must
be in the AusPost next-day network, eParcel Express must be selected, and the order must be placed
before 2PM AEST Mon-Thurs excluding NSW Public Holidays. Orders may be delayed due to AusPost
pickup timings and order verifications. eParcel Express is typically a 1-day service within the
AusPost next-day network, though it is sometimes 2+ days.
Recommended Essentials:
Building on the success of the original AI HAT, the AI HAT+ 2 delivers next‑generation artificial‑intelligence performance to the Raspberry Pi 5. Powered by the Hailo 10H neural‑network accelerator and equipped with 8 GB of high‑speed LPDDR4X‑4267 SDRAM, this board brings powerful LLM and VLM capabilities, along with the previous models' machine vision capabilities to the edge - perfect for offline, local AI workloads or robotics projects.
Key Features
- Hailo 10H accelerator – up to 40 TOPS @ INT‑4 and 20 TOPS @ INT‑8
- On‑board 8 GB LPDDR4X‑4267 SDRAM for loading larger models directly on the HAT
- Runs large language models (LLMs) such as QWEN and Llama 3 B, and vision models (YOLO, etc.) with the same performance as the 26 TOPS HAT+
- Optimised for power‑efficient edge AI – ideal for local, offline inference
- Supports both LLMs and VLMs, enabling chat‑GPT‑style interactions, home‑automation decision‑making, robotics, and more
- Future‑proof: updates to models will keep the HAT useful into the future
- Uses the PCIe connector – only compatible with Raspberry Pi 5
Compatibility & Installation
- Works with an active cooler mounted to the Pi 5 SBC
- Designed to fit the Official Raspberry Pi 5 Case (Remove the in-built fan and top plate)
- PCIe connection cable included for a clean, low‑profile installation
Highlights
The AI HAT+ 2 delivers up to 40 TOPS (INT‑4) and 20 TOPS (INT‑8), matching the vision‑model performance of the 26 TOPS HAT+ while adding LLM capability. This makes it an ideal platform for:
- Running sophisticated language models for chat‑bot or decision‑support applications
- Processing visual data with YOLO‑style detection and other computer‑vision pipelines
- Deploying AI in resource‑constrained environments where power and space are limited
Product Contents
- AI HAT+ 2 board
- Heatsink for the chipset
- Stacking header
- PCIe connection cable
- Standoffs for secure mounting
Technical Specifications
- Neural‑network accelerator: Hailo 10H
- Memory: 8 GB LPDDR4X‑4267 SDRAM
- Interface: PCIe (Raspberry Pi 5 only)
- Performance: 40 TOPS @ INT‑4, 20 TOPS @ INT‑8
- Power efficiency: Optimised for low‑power edge operation
Resources
- Getting Started Guide
- Blog Post
Building on the success of the original AI HAT, the AI HAT+ 2 delivers next‑generation artificial‑intelligence performance to the Raspberry Pi 5. Powered by the Hailo 10H neural‑network accelerator and equipped with 8 GB of high‑speed LPDDR4X‑4267 SDRAM, this board brings powerful LLM and VLM capabilities, along with the previous models' machine vision capabilities to the edge - perfect for offline, local AI workloads or robotics projects.
Key Features
- Hailo 10H accelerator – up to 40 TOPS @ INT‑4 and 20 TOPS @ INT‑8
- On‑board 8 GB LPDDR4X‑4267 SDRAM for loading larger models directly on the HAT
- Runs large language models (LLMs) such as QWEN and Llama 3 B, and vision models (YOLO, etc.) with the same performance as the 26 TOPS HAT+
- Optimised for power‑efficient edge AI – ideal for local, offline inference
- Supports both LLMs and VLMs, enabling chat‑GPT‑style interactions, home‑automation decision‑making, robotics, and more
- Future‑proof: updates to models will keep the HAT useful into the future
- Uses the PCIe connector – only compatible with Raspberry Pi 5
Compatibility & Installation
- Works with an active cooler mounted to the Pi 5 SBC
- Designed to fit the official Raspberry Pi 5 case (confirmation pending); if not, a compatible case such as the KKSB HAT Case is recommended
- PCIe connection cable included for a clean, low‑profile installation
Highlights
The AI HAT+ 2 delivers up to 40 TOPS (INT‑4) and 20 TOPS (INT‑8), matching the vision‑model performance of the 26 TOPS HAT+ while adding LLM capability. This makes it an ideal platform for:
- Running sophisticated language models for chat‑bot or decision‑support applications
- Processing visual data with YOLO‑style detection and other computer‑vision pipelines
- Deploying AI in resource‑constrained environments where power and space are limited
Product Contents
- AI HAT+ 2 board
- Heatsink for the chipset
- Stacking header
- PCIe connection cable
- Standoffs for secure mounting
Technical Specifications
- Neural‑network accelerator: Hailo 10H
- Memory: 8 GB LPDDR4X‑4267 SDRAM
- Interface: PCIe (Raspberry Pi 5 only)
- Performance: 40 TOPS @ INT‑4, 20 TOPS @ INT‑8
- Power efficiency: Optimised for low‑power edge operation
- Works with Active cooler
WE CAN TODO CONFIRM
- Fits in Official case
- If not, what case? - KKSB HAT CASE?
Discussion points
- Building on success of original AI HAT
- Capable of running LLMs and VLMs - along with the same vision models (YOLO etc) with the same level of performance as the 26TOPS HAT+
- Made for AI on the edge, or local and offline
- Power efficient
- Expected to run models like QWEN and Llama (3B)
- A lot of the questions we got were 'Can I run something similar to chatgpt on the AI HAT" - now you can
- Would be perfect for general questions, and decision making - home automation, robots,
- As models get better so will this HAT
- Uses the PCIe connector - only compatible with the Pi 5
Short desc options
- Give your Pi 5 an AI boost: low‑power, offline inferencing that can power chat assistants, vision detection and decoding, and robots.
- A powerful and versatile machine learning HAT for the Pi 5 - run LLMs, VLMs and conventional vision models.
- Transform your Pi 5 into an edge‑AI powerhouse, with low‑power offline operation for chat‑bots, visual detection, and robotics.
