20kg.cm Bus Servo Motor, 106PRM High Speed, Large Torque, With 360 Degrees High Precision Magnetic Encoder, Two-way Feedback, Servo/Motor Mode Switchable 20kg.cm High Speed Bus Servo Motor
Large Torque | 360° High Precision Magnetic Encoder | 106PRM High Speed
PRODUCT TYPE | ST3215-HS bus servo motor |
---|---|
TORQUE | 20kg.cm@12V |
ROTATION ANGLE | 360° (0~4095) |
POSITION SENSOR RESOLUTION | 360° / 4096 |
MECHANISM LIMITED ANGLE | No Limit |
OPERATING VOLTAGE | 6 ~ 12.6 V |
GEAR | high precision metal gear |
NO-LOAD SPEED | 0.094sec / 60° (106RPM) |
Encoder TYPE | 360° Magnetic Encoder |
ID RANGE | 1 ~ 253 |
BAUDRATE | 38400bps ~ 1Mbps (1Mbps by default) |
FEEDBACK | Position, Load, Speed, Input Voltage |
NO-LOAD CURRENT | 240 mA |
LOCKED-ROTOR CURRENT | 2.4A |
kt | 8.3kg.cm/A |
