Search results for: 'usb breakout board'

We're always on the look out for better ways to make projects portable: being able to charge your battery in the most convenient manner…

This is a USB 2.0 type B to Micro-B 5-pin black cable. You know, the mini-B connector that usually comes with cell phones, Cameras, MP3 players, etc. We specifically like these 6" long cables because using USB peripherals in projects within a small enclosure is much easier these days, and most times you really don’t need six feet of cable to do that. You can still use this USB cable with our Micro-USB LiPo Charger Basic, Pro Micros, Micro-B USB breakout, or anything else that utilizes a Micro-B connector type!

This USB-to-serial adapter lets you easily connect a TTL serial device to a PC by acting as a virtual serial port. The board is a Micro-USB carrier for ...

A handy USB interface board for connection to a S 1147 joystick and up to 12 arcade buttons. It connects into any device that supports a USB joystick. Includes pre-terminated interface leads with 6.3mm spade plugs. This board appears as a simple driverless USB interface, recognised by most operating systems as a HID. For full wiring information, there are a number of online guides available depending on the arcade project you are building.

This is SparkFun Beefy 3 FTDI Basic Breakout for the FTDI FT231X USB to serial IC. The pinout of this board matches the FTDI cable to work with official Arduino and cloned 3.3V Arduino boards. It can also be used for general serial applications. Built upon the same foundation as our 3.3V SparkFun FTDI Basic Breakout, the Beefy 3 is equipped with an AP2112K voltage regulator making this FTDI basic breakout board capable of handling a current load of up to 600 mA! With the addition of a more “Beefy” voltage regulator your will now be able to power a 3.3V project directly from the FTDI. The pinout of this board matches the FTDI cable to work with official Arduino and cloned 3.3V Arduino boards.

This is the newest revision and fixes issues with the last board. This breakout board pairs an SP3485 RS-485 transceiver with an FT232RL USB UART IC to convert a USB stream to RS-485. The SP3485 is a half-duplex transceiver, so it can only communicate one way at a time, but it can reach transmission speeds of up to 10Mbps.

Getting touchy performance with your screen's touch screen? Resistive touch screens are incredibly popular as overlays to TFT and LCD displays. If you want to connect...

This cable is not only super-fashionable, with a woven pink and purple Blinka-like pattern, it's also made for USB C for our modernized breakout boards, Feathers and more. If you want something just like it but for Micro B, we have a B version here.

This is a new version of the FTDI breakout board features an Atmega8U2 programmed as a USB-to-serial converter, the same chip found on the Arduino Uno.

This breakout board for Texas Instruments’s TPS2113A autoswitching power multiplexer allows you to select which of two power sources is connected to a load while blocking reverse current into either of the sources. It has an adjustable current limit that can be set as high as 2 A and an adjustable switching threshold. Each input power rail on the multiplexer can be supplied with 2.8 V to 5.5 V, and the board also breaks out a USB Micro-B connector that can be used to supply one of the rails.
