Search results for: 'i2c multiplexer'

This Gravity: I2C HUB module is designed to connect up to 8 I2C devices to a main-controller, which allows you easily to hook up multiple I2C devices in project...

This is a breakout board for the very handy 16-Channel Analog/Digital Multiplexer/Demultiplexer CD74HC4067. This chip is like a rotary switch - it internally routes the common pin (COM in the schematic, SIG on the board) to one of 16 channel pins (CHANxx). It works with both digital and analog signals (the voltage can’t be higher than VCC), and the connections function in either direction. To control it, connect 4 digital outputs to the chip’s address select pins (S0-S3), and send it the binary address of the channel you want (see the datasheet for details). This allows you to connect up to 16 sensors to your system using only 5 pins!

I2C Hub Grove is an extension Grove module for connecting multiply I2C devices to Grove Base Shield. It can use with Universal 4 Pin to X2 4 Pin cable...

Easily change I2C sensor addresses with DFRobot’s plug-and-play I2C address shifter. Fix I2C conflicts, support multiple sensors, and simplify wiring....

Adafruit has hundreds of designs that use I2C - a two-wire protocol that can let you quickly connect sensors, OLEDs, GPIO expanders, and more. Folks love...

Analog switches are a solid state alternative to relays, when you want a smaller, lower-power technology that won't wear out mechanically. And, as the...

Qwiic, or STEMMA QT, is a very efficient way to quickly prototype an idea, but a lot of Qwiic/Stemma QT driver boards only have one port, and devices have two ports but that's only good for chaining. This Multiport board allows boards that have only one Stemma QT/Qwiic port to be added to the I2C bus. Or, use this hub to add as many I2C devices to the bus as you need. Complete with mounting holes so the board can be added to any system.
