Argon ONE v3 NVMe PCIe Expansion Board for Raspberry Pi 5

Power up your Pi 5 and Argon ONE V3 case with an NVMe SSD using this expansion board.

This expansion board replaces the stock standard one that comes with the basic Argon One v3 Pi 5 Case, and gives you the space and functionality to connect a M.2 NVMe drive to your Pi.

With the power of an NVMe SSD, you'll have faster boot times, and much more storage than typical microSD cards.

Use the included NVMe FPC to connect to the dedicated port on the back of the Raspberry Pi.

Note: does not work with ONE V1 or V2 cases (For the Pi 4)

Features:

• Argon ONE V3 M.2 NVME PCIE Expansion Board further expands your Raspberry Pi 5 and Argon ONE V3.
• Boot your Raspberry Pi 5 from an NVME M.2 Drive.
• Built-in HEATSINK for your M.2 NVME Drive
• Enjoy faster and higher storage access by connecting M.2 NVME drives via the PCIe slot on the Raspberry Pi 5
• Versatile M.2 NVME support compatible with any M.2 NVME with M-Key up to 2280 size
• Greater thermal management on M.2 NVME with included aluminum heatsink specific to M.2 drive to keep it cool, efficient and working longer
• Reliable and consistent data transfer with included FPC impedance controlled cable

M.2 NVMe Drive Compatibility:

Other drives may also be compatible but have not been tested yet, if you want to add one to the list, reach out and let us know!

• Western Digital SN850
• Western Digital SN740
• Western Digital SN570
• Western Digital SN530
• Western Digital Black SN750 SE (Phison Controller)
• Team MP33
• Samsung 980 Pro
• Samsung 980
• Sabrent Rocket Nano
• Sabrent Rocket 4.0
• PNY CS1030
• Origin Inception TLC830 Pro NVMe
• Netac NV3000 NVMe SSD
• Netac NV2000 NVMe SSD
• Lexar NM710
• Lexar NM620
• Kioxia Exceria NVMe SSD
• Kioxia Exceria G2 NVMe SSD
• Kingston KC3000
• Kingston SNV2S NV2 Gen4 PCIe NVMe M.2 2280 Solid-State Drive
• Inland PCIe NVMe SSD
• Crucial P3 Plus M.2
• Crucial P3 M.2
• Crucial P2 M.2
• Axe Memory Generic Drive
• AData XPG SX8200 Pro

Documents

• Assembly Guide
