1.69inch Round LCD Display Module with Touch Panel

SKU: WS-27057 Brand: Waveshare
1.69inch Round LCD Display Module with Touch panel, Micro LCD Display, 240×280 Resolution, IPS, SPI And I2C Communication, 262K Display Color...
$24.70 AUD, inc GST
$22.45 AUD, exc GST

In stock, ships same business day if ordered before 2PM
Delivered by Tue, 26th of Nov

Quantity Discounts:

  • 10-25 $21.55 (exc GST)
  • 25+ $20.88 (exc GST)
- +

1 from local stock, 1 supplier stock; your order will dispatch between Dec 1 to Dec 10. And yes, stock levels and lead times are accurate!

Shipping:

  • $7+ Standard (5+ days*, tracked)
  • $11+ Express (2+ days*, tracked)
  • FREE Pickup (Newcastle only - must order online*)

Shipping costs may increase for heavy products or large orders.

Exact shipping can be calculated on the view cart page.

*Conditions apply, see shipping tab below.

This display offers a 240×280 resolution and supports 262K colors, delivering a vivid and clear viewing experience. Its touchscreen has high transmittance, providing a fast response and long-lasting durability. With an embedded ST7789V2 driver chip and CST816T capacitive touch control chip, it uses SPI and I2C communication to reduce the number of required IO pins, making it compatible with a range of controller boards like Raspberry Pi, ESP32S3, Raspberry Pi Pico, Arduino, and STM32.

Specifications

  • Operating voltage: 3.3V / 5V
  • Resolution: 240 × 280 pixels
  • Display Driver: ST7789V2
  • Touch Driver: CST816T
  • Display Interface: 4-wire SPI
  • Touch Interface: I2C
  • Display Panel: IPS
  • Touch Type: Capacitive
  • Display size: 27.972 × 32.634 mm
  • Pixel size: 0.11655 × 0.11655 mm
  • Module size: 33.13 × 41.13 mm

Pinout

1.69inch Touch LCD display, onboard components

VCC Power (3.3V / 5V input)
GND Ground
LCD_DIN SPI MOSI pin
LCD_CLK SPI Clock pin
LCD_CS LCD Chip Selection, low active
LCD_DC LCD Data/Command selection (high for data, low for command)
LCD_RST LCD Reset, low active
LCD_BL LCD Backlight
TP_SDA TP Data pin
TP_SCL TP Clock pin
TP_RST TP Reset, low active
TP_IRQ TP Interrupt pin



1.69inch Touch LCD Module RASPBERRY PI (BCM) ESP32S3 Pico Arduino STM32
VCC 3.3V 3.3V 3.3V 5V 3.3V
GND GND GND GND GND GND
LCD_DIN 10 11 GP11 11 PA7
LCD_CLK 11 10 GP10 13 PA5
LCD_CS 8 9 GP9 10 PB6
LCD_DC 25 8 GP14 7 PA8
LCD_RST 27 14 GP8 8 PA9
LCD_BL 18 2 GP15 9 PC7
TP_SDA 2 6 GP6 SDA PB9
TP_SCL 3 7 GP7 SCL PB8
TP_RST 17 16 GP16 4 PA10
TP_IRQ 4 17 GP17 3 PB10

Dimensions

1.69inch Touch LCD display, outline dimensions

Documents

Shipping List

  • 1 x 1.69inch Touch LCD Module
  • 1 x GH1.25 12Pin cable

This product is listed in:

Displays & Screens>Round Displays
