ATmega328P-PU Atmel AVR Microcontroller

SKU: 002-556-ATMEGA328P-PU

$7.95 AUD, inc GST
$7.23 AUD, exc GST
ATmega328P-PU Atmel AVR Microcontroller
7.95 AUD

SKU: 002-556-ATMEGA328P-PU

$7.95 AUD, inc GST
$7.23 AUD, exc GST
6 reviews 0 5 4.9
Shipping Offer


  • $6.95 Standard (2-4 days, tracked)
  • $8.95 Express (Overnight*, tracked)
  • $3 Economy Post* (3-7 days, no tracking)
  • FREE Pickup (Newcastle only)

Shipping costs may increase for heavy products or large orders.

Exact shipping can be calculated on the view cart page.

*Conditions apply, see shipping tab below.


  • Controller Family/Series: AVR MEGA
  • Core Size: 8bit
  • No. of I/O's: 23
  • Program Memory Size: 32 KB
  • EEPROM Memory Size: 1KB
  • RAM Memory Size: 2KB
  • CPU Speed: 20MHz
  • Oscillator Type: External, Internal
  • No. of Timers: 3
  • Peripherals: ADC, Comparator, RTC
  • Embedded Interface Type: I2C, SPI, USART
  • No. of PWM Channels: 6
  • Digital IC Case Style: DIP
  • Supply Voltage Range: 1.8V to 5.5V
  • Operating Temperature Range: -40°C to +85°C


This product is listed in:

Documentation and Resources:
  • The Maker Revolution
  • The Maker Revolution celebrates the creation of new devices and the modification of existing ones - the transition from a consumer buying goods to eventually having a major part in their creation. The Maker Revolution places strong emphasis on free (...
  • grinder_timer
  • Making a dumb coffee grinder slightly less dumb. This is a programmable timer tethered to a Rancilio Rocky coffee grinder. The Rocky is a "dumb" grinder and electrically very simple. Basically it's an ac motor with an on/off switch and a momentary push-button to grind. This project adds an electronic timer so that repeatable grind quantities can be produced without having to stand over the grinder. Features: - Four programmable ...

Product Comments

Customer Reviews

  1. Review by Alek verified purchaser

    Controlling away quite nicely as a "minimal" Arduino (Posted on 17/07/2017)

  2. Review by Chris verified purchaser

    A great microcontroller. (Posted on 10/04/2017)

  3. Review by Case verified purchaser

    All products have met my expectations. Thanks (Posted on 15/08/2016)

  4. Review by Mike - Does the job verified purchaser

    I bought this microcontroller without the boot-loader because it was cheaper and it is easy to put one in if you already have a project board and a few jumper wires already. Since then I have reset the internal fuses to run on the internal oscillator at 8 MHz and installed the boot-loader using Nick Gammons excellent posts. So far so good - this project has a way to run. I liked the cheap postage, thanks guys. (Posted on 17/06/2015)

  5. Review by Hans - Core Electronics, my favorite shop in Oz. Good quick service. verified purchaser

    I have been dealing with Core electronics for a while now and there is honestly not a single cause for complaints. Their service is quick and prices and shipping are low.
    Best of all, Graham is approachable when help or advice is needed.
    Shipping 2-3 days, beats the long wait from China. H (Posted on 10/11/2014)

  6. Review by Michael - AVR works well as Arduino replacement verified purchaser

    This AVR works well as an Arduino replacement for incorporating permanently into circuits. There is more flash space without the bootloader, it draws less power without the supporting chips, and it is cheaper.
    The downsides are that you'll need an ICSP (or similar) to program it, there's no easy USB interface, and there's two analogue pins missing compared to an Arduino Nano. (Posted on 7/03/2014)
