3-pin LiPo Battery 20000mAh

This 20000mAh Lithium-Ion battery is great for when you want to monitor the temperature of your battery as it heats up from use.

We offer a range of 3-pin LiPos:

• 500mAh Battery
• 800mAh Battery
• 1000mAh Battery
• 4000mAh Battery
• 6000mAh Battery
• 10000mAh Battery

Wire Handling Warning:
The battery wires and connector are delicate. Avoid pulling, bending, twisting, or repeatedly moving the wires, as this can damage the connection or battery. Handle the battery by its body only, and keep wire movement to a minimum during installation and use.

Specifications

• Capacity: 20000mAh
• Max Discharge: 4A
• Dimensions: 22mm x 65mm x 110mm
• Standard 3-pin JST-PH connector
• Cable length: 100mm
• Weight: 360g
• Onboard NTC Temperature Sensor
• Volts: 3.7
• Type: Li-Polymer
• Built-in protection circuit PCM for prevent overcharging or over-discharging. The PiJuice Zero also has this feature.

Documents

• PCM Datasheet
• MSDS
