RAKBox-B5 Transparent Acrylic Enclosure

SKU: RW-910010 Brand: RAKwireless

A transparent acrylic enclosure offers open, stackable PCB protection in a 105×75×30 mm design. Perfect for benchtop prototyping with the WisBlock ecosystem.

$23.14 AUD, inc GST
$23.14 AUD, exc GST

In stock, ships same business day if ordered before 2PM
Delivered by Tue, 7th of Apr

Quantity Discounts:

  • 10+ $22.21 (exc GST)
  • 25+ $21.52 (exc GST)
- +

4 from local stock, 1 supplier stock; your order will dispatch between Dec 1 to Dec 10. And yes, stock levels and lead times are accurate!

Shipping:

  • $7+ Standard (5+ days*, tracked)
  • $11+ Express (2+ days*, tracked)
  • FREE Pickup (Newcastle only - must order online*)

Shipping costs may increase for heavy products or large orders.

Exact shipping can be calculated on the view cart page.

*Conditions apply, see shipping tab below.

This transparent acrylic enclosure safeguards your WisBlock PCB modules while offering an open-frame design for effortless assembly and stacking. Whether you’re engineering a custom IoT prototype or teaching rapid hardware integration, its modular format adapts seamlessly to diverse project requirements.

Technical Specifications

  • Dimensions (W x L x H): 105 mm x 75 mm x 30 mm
  • Weight: approximately 120 g (4.23 oz)
  • Material thickness: 3 mm cover, 5 mm base

Resources

How to Use/Installation

  1. Position the WisBlock Base (RAK19007) on the base plate and secure with the supplied standoffs.
  2. Stack the Core board (RAK4631) and additional sensor or wireless modules, ensuring pin-header alignment.
  3. Place the transparent cover over the assembled stack, aligning the fixing holes.
  4. Insert a battery into the battery holder and clip it into the compartment.
  5. Fasten all screws, taking care not to over-torque and stress the acrylic.
  6. To expand your setup, simply reverse these steps, add modules, and reassemble.

Compatibility

Module Type Model
WisBlock Base RAK19007
WisBlock Core RAK4631
WisBlock Wireless RAK2305
WisBlock Wireless RAK5860
WisBlock Sensor RAK1901
WisBlock Sensor RAK1902
WisBlock Sensor RAK1904
WisBlock Sensor RAK1906
WisBlock Sensor RAK1910
WisBlock Interface RAK5801
WisBlock Interface RAK5802
WisBlock Interface RAK5811
WisBlock Interface RAK5804
WisBlock Interface RAK1920
WisBlock Display RAK1921

What’s Included

  • Enclosure (cover and base)
  • Battery holder
  • Assembly screws and standoffs
