Ultrasonic ToF Material Detection Sensor

Skip to the beginning of the images gallery

Ultrasonic ToF Material Detection Sensor

SKU: SEN0560 Brand: DFRobot

This ultrasonic material detection sensor can determine the material within short distance of 2-10cm, detect materials with ease using our ultrasonic...

$22.95 AUD, inc GST

$20.86 AUD, exc GST

Available with a lead time
Expect dispatch between Dec 02 and Dec 04

Quantity Discounts:

10-25 $20.03 (exc GST)
25+ $19.40 (exc GST)

This ultrasonic time-of-flight (ToF) sensor utilizes the difference in energy of the ultrasonic echo signal on various surfaces to identify materials. Featuring ultra-low power, small size, and light weight, the ultrasonic material detection sensor is specially designed for material identification within a short range of 2-10cm.

The ultrasonic sensor can distinguish hard and soft materials and output information by IO (high/low) or UART. Compact and easy to install, it is mainly suitable for robotic cleaners to identify the floor material and automatically adjust the cleaning strategy according to the recognized ground information, thus achieving intelligent cleaning.

Material inspection of Ultrasonic Material Detection Sensor

Figure: Material inspection

Assembly diagram of Ultrasonic Material Detection Sensor

Figure: Assembly diagram

Ultrasonic Material Detection Sensor Parameter description of FOV

Figure: Parameter description of FOV

Ultrasonic Material Detection Sensor Parameter description of FOV

Figure: FOV 45° Scan Area

Features

Small size & light weight

Wide effective distance range for detecting material

Wide effective FOV for detecting material

High reliability

Ultrasonic principle

Miniature and ultra-low-power

Easy to embed

Applications

Intelligent Cleaning

Specification

Input Voltage: 3.3V

Start-up Current: 50mA

Operating Current: 8mA

Driving Frequency: 175KHz

Detection Range: 2 to 10cm

Detection Frequency: 100Hz

FOV: 45°

Operating Temperature:-10°C to 50°C

Storage Temperature: -30°C to 70°C

Lifetime: 3000h

EDS Protection Level: 15KV

Protection Level: IP54

Communication Mode: UART/IO

Weight: 1.0g (wires not included)

Documents

Product wiki

Parts List

Ultrasonic Material Detection Sensor × 1

ZH1.5T-4P DuPont Connector × 1
