ESP8266 SMT Module - ESP-12S

Rating:

100% of 100

SKU: ADA2491 Brand: Espressif ESP32 & ESP8266

Add Internet to your next project with an adorable, bite-sized WiFi microcontroller, at a price you like! The ESP8266 processor from Espressif is an 80 MHz microcontroller...

$12.95 AUD, inc GST

$11.77 AUD, exc GST

Available with a lead time
Expect dispatch between Nov 28 and Dec 03

Quantity Discounts:

10-25 $11.42 (exc GST)
25+ $11.18 (exc GST)

Add Internet to your next project with an adorable, bite-sized WiFi microcontroller, at a price you like! The ESP8266 processor from Espressif is an 80 MHz microcontroller with a full WiFi front-end (both as client and access point) and TCP/IP stack with DNS support as well. Adafruit do sell these on a breakout, but maybe you wanna just put this in your own project PCB.

Please note that this product may ship as an ESP-12S or a ESP-F. The only difference between the two are the pads along the bottom - which are used for interfacing with the Flash though serve no purpose for GPIO.

These modules are very easy to hand solder, with big pads! Adafruit have this part in the Adafruit Eagle library (ESP12) - the extra pads don't appear but they are not usable anyways.

Comes with 4MB flash chip, ESP processory, and onboard antenna. These come pre-progammed with the NodeMCU Lua firmware, so you are ready to rock. Some extra parts will be needed to get this going, check out the HUZZAH schematic for the extra components Adafruit recommend

For advanced users only! This product is just the module - which can be difficult to use. Click here if you're looking for the Huzzah ESP8266 Breakout!

Technical Details

Dimensions: 24mm x16mm x 3mm / 0.9" x 0.6" x 0.1"
Weight: 2g
4MB Flash
ESP8266 specification sheet
FCC test report for the module (FCC ID: 2AHMR-ESP12S)
Huuuuge amount of information on http://www.esp8266.com/ community forum!
NodeMCU (Lua for ESP8266) webpage with examples and documentation on the Lua framework
Arduino IDE support for ESP8266
Don't forget to visit esp8266.com for the latest and greatest in ESP8266 news, software and gossip!

As of December 1, 2016 Adafruit are shipping the ESP-12S version which no longer has the SPI flash pads brought out on the bottom row. Note that you couldn't use them for GPIOs or anything, they were there so you could program the FLASH chip only.
