ESP32-S3 Mini Development Board

Rating:
100% of 100
SKU: WS-25081 Brand: Waveshare
ESP32-S3 Mini Development Board, Based on ESP32-S3FH4R2 Dual-Core Processor, 240MHz Running Frequency, 2.4GHz Wi-Fi & Bluetooth 5...
$9.20 AUD, inc GST
$8.36 AUD, exc GST

In stock, ships same business day if ordered before 2PM
Delivered by Tue, 24th of Dec

Quantity Discounts:

  • 10-25 $8.03 (exc GST)
  • 25+ $7.78 (exc GST)
- +

69 from local stock, 1 supplier stock; your order will dispatch between Dec 1 to Dec 10. And yes, stock levels and lead times are accurate!

Shipping:

  • $7+ Standard (5+ days*, tracked)
  • $11+ Express (2+ days*, tracked)
  • FREE Pickup (Newcastle only - must order online*)

Shipping costs may increase for heavy products or large orders.

Exact shipping can be calculated on the view cart page.

*Conditions apply, see shipping tab below.

ESP32-S3 Mini Development Board, Based on ESP32-S3FH4R2 Dual-Core Processor, 240MHz Running Frequency, 2.4GHz Wi-Fi & Bluetooth 5

Based on ESP32-S3FH4R2, onboard multi-function GPIO pins

Castellated Module, Suitable For SMD Applications

Specifications

  • Equipped with Xtensa® 32-bit LX7 dual-core processor, up to 240MHz main frequency
  • Supports 2.4GHz Wi-Fi (802.11 b/g/n) and Bluetooth® 5 (LE)
  • Built in 512KB of SRAM and 384KB ROM, onboard 4MB Flash memory and 2MB PSRAM
  • Castellated module and onboard ceramic antenna, allows soldering direct to carrier boards
  • Supports flexible clock, module power supply independent setting, and other controls to realize low power consumption in different scenarios
  • Integrated with USB serial port full-speed controller, 34 × GPIO pins allows flexibly configuring pin functions
  • 4 × SPI, 2 × I2C, 3 × UART, 2 × I2S, 2 × ADC, etc.

What's On Board

  1. ESP32-S3FH4R2 dual-core processor up to 240MHz operating frequency
  2. USB Type-C Port
  3. ME6217C33M5G low dropout LDO, 800mA (Max)
  4. WS2812 RGB LED
  5. 2.4G ceramic antenna
  6. BOOT button Press it and then press the RESET button to enter download mode
  7. RESET button
  8. ESP32-S3FH4R2 pins

Pin definition

Dimensions

Resources
