Search results for: 'plastic gears'

Do you need a servo for a tiny little project? Or are you seeking for an affordable solution? This mini metal servo is quite impressive, it does quite the job for a large range of tasks. With metal gear, it could gives you a 1.8kg*cm torque. Pretty strong regarding its size. Suitable for Beam robots and other automation tasks. Keep in mind that if you need some heavy lifting you should be considering some of our other options. This servo is for you if you are planning on building smaller size robots.

This 40 tooth servo gear is most commonly used to drive the 80.....

The Kitronik 180 degree rotation clippable servo features crocodile clips instead of a servo connector, durable metal gears, 4 horns and high torque output.

The Kitronik 360 degree rotation clippable servo features crocodile clips instead of a servo connector, Lightweight plastic gears, 4 horns & high torque...

This gearmotor is a powerful brushed DC motor with 150:1 metal gearbox intended for operation at 12 V. The gearbox is composed mainly of spur gears, but it features helical gears for the first stage for reduced noise and improved efficiency. These units have a 16 mm-long, 6 mm-diameter D-shaped output shaft. This gearmotor is also available with an integrated encoder.

This gearmotor is a powerful brushed DC motor with 70:1 metal gearbox intended for operation at 12 V. The gearbox is composed mainly of spur gears, but it features helical gears for the first stage for reduced noise and improved efficiency. These units have a 16 mm-long, 6 mm-diameter D-shaped output shaft. This gearmotor is also available with an integrated encoder.

The FEETECH FT5335M servo is all about torque. This 1/4-scale digital servo can deliver an incredible 550 oz-in of torque at 7.4 V or 480 oz-in at 6 V thanks to its powerful motor and all-metal gear train. The FT5335M is a high-voltage servo, offering an operating voltage range of 6 V to 7.4 V. Servo horns and associated hardware are included. This servo can work with both 5 V and 3.3 V servo signals.

This tiny, cylindrical gearmotor consists of a coreless brushed DC motor and a 26:1 plastic planetary gearbox. The entire assembly has a diameter of just 6 mm (0.24″) and an extremely light weight of 1.2 g (0.042 oz), making it a great actuator for miniature robots and very small mechanisms. Key specs at 6 V: 2500 RPM and 35 mA free-run, 1.5 oz-in (0.1 kg-cm) and 400 mA stall.

This tiny, cylindrical gearmotor consists of a coreless brushed DC motor and a 136:1 plastic planetary gearbox. The entire assembly has a diameter of just 6 mm (0.24″) and an extremely light weight of 1.3 g (0.046 oz), making it a great actuator for miniature robots and very small mechanisms. Key specs at 6 V: 500 RPM and 45 mA free-run, 8 oz-in (0.6 kg-cm) and 400 mA stall.

This gearmotor is a powerful brushed DC motor with 150:1 metal gearbox intended for operation at 24 V. The gearbox is composed mainly of spur gears, but it features helical gears for the first stage for reduced noise and improved efficiency. These units have a 16 mm-long, 6 mm-diameter D-shaped output shaft. This gearmotor is also available with an integrated encoder.

The motor requires a voltage between 4.5-9V, has a gearbox ratio of 1:48 and a speed of 140RPM at 4.5V...

This tiny, cylindrical gearmotor consists of a coreless brushed DC motor and a 5.1:1 plastic planetary gearbox. The entire assembly has a diameter of just...

This compact, inexpensive plastic gearmotor (brushed DC motor with a 180:1 reduction gearbox) is well suited for use in small robots. While intended for operation at 4.5 V, it should run comfortably in the 3 V to 6 V range. The gearbox has a 0.38″-long, 3 mm-diameter D-shaped output shaft that is offset from but parallel to the motor shaft, and a built-in safety clutch helps protect the gears from excessive loads. Key specs at 4.5 V: 80 RPM and 80 mA free-run, 30 oz-in (2.2 kg-cm) and 0.8 A stall.

This 228:1 gearbox with brushed DC motor has a low-current motor and provides power and speed that is comparable to an RC servo at a fraction of the cost. At 6 V, it has a free-run speed of 45 RPM and a stall torque of approximately 100 oz-in. Though the product picture shows two gearmotors, this product is for a single motor.

This tiny, cylindrical gearmotor consists of a coreless brushed DC motor and a 700:1 plastic planetary gearbox. The entire assembly has a diameter of just...

It looks like a micro servo, it acts like a micro servo, but it's more than just a micro servo! Adafruit got a factory to custom-make these classic 'micro' sized hobby...

Here, for all your mechatronic needs, is a simple, high quality continuous full-rotation servo motor. This servo is able to take in 6 volts and deliver 66.7 oz-in. of maximum torque at 70 r/min.

Here, for all your mechatronic needs, is a simple, high quality continuous full-rotation servo motor. This servo is able to take in 6 volts and deliver 30.6 oz-in. of maximum torque at 0.14 sec/60°

The Hitec HS-788HB servo is based around the long-time favorite, the HS-785HB. This new model was created with a 25 tooth output spline in.....

This is a simple ~140RPM (no load), DC planetary gearmotor. This motor is great for various applications such as robotics, electric locks, household automation...

This gearmotor is a powerful brushed DC motor with 10:1 metal gearbox intended for operation at 12 V. The gearbox is composed mainly of spur gears, but it features helical gears for the first stage for reduced noise and improved efficiency. These units have a 16 mm-long, 6 mm-diameter D-shaped output shaft. This gearmotor is also available with an integrated encoder.

This gearmotor is a miniature (0.94" x 0.39" x 0.47"), low-current brushed DC motor with 4.995:1 metal gearbox, similar to Sanyo’s popular 12 mm gearmotors. These units have a 0.365"-long, 3 mm-diameter D-shaped output shaft. Key specs at 6 V: 2500 RPM and 50 mA free-run, 1 oz-in (0.1 kg-cm) and 0.36 A stall.

This gearmotor is a miniature (0.94" x 0.39" x 0.47"), low-current brushed DC motor with 100.37:1 metal gearbox, similar to Sanyo’s popular 12 mm gearmotors. These units have a 0.365"-long, 3 mm-diameter D-shaped output shaft. Key specs at 6 V: 120 RPM and 40 mA free-run, 12 oz-in (0.9 kg-cm) and 0.36 A stall.

This version of the FT1117M miniature servo from FEETECH is specially modified to provide access to the feedback potentiometer through a fourth (green)...

This gearmotor is a miniature (0.94" x 0.39" x 0.47"), high-quality, low-current motor with 297.92:1 metal gearbox, similar to Sanyo’s popular 12 mm gearmotors. These units have a 0.365"-long, 3 mm-diameter D-shaped output shaft. Key specs at 6 V: 45 RPM and 30 mA free-run, 40 oz-in (2.9 kg-cm) and 0.36 A stall.
