USB GPS Receiver

Rating:

100% of 100

SKU: TEL0137 Brand: DFRobot

This GPS receiver brings much more accurate and faster positioning performance with stronger signal compared with traditional GPS receivers. It is compact, lightweight...

$22.15 AUD, inc GST

$20.14 AUD, exc GST

In stock, ships same business day if ordered before 2PM
Fastest delivery: Tomorrow* Disclaimer:
The shipping address needs to be in the AusPost next day network and eParcel Express is chosen during checkout. On rare occasions, orders may be delayed by up to one business day due to AusPost pickup timings or for order verifications.

Quantity Discounts:

10-25 $19.33 (exc GST)
25+ $18.73 (exc GST)

This GPS receiver brings much more accurate and faster positioning performance with stronger signal compared with traditional GPS receivers. It is compact, lightweight and portable. Integrated with built-in receiving antenna, this product adopts a high-precision positioning chip and industrial-grade manufacturing process so that it can meet the positioning requirements of both industrial-grade and personal use. The GPS receiver has battery inside for supplying power for storing satellite data, such as satellite signal status, final position and time that would greatly increase the positioning speed at the module’s next boot. In addition, this receiver adopts USB interface, which can be conveniently used in maincontrollers like Raspberry Pi, NVIDIA, LattePanda. It is suitable for vehicle navigation, handheld positioning, wearable devices and other fields.

Dimension

Specifications:

Chip: UBX-G7020-KT
Frequency: L1, 1575.42MHz/L2,1561.10MHZ/L3,1602.00MHZ
Baud Rate: 4800,9600,19200,38400,57600,115200bps
Receiving Channel: 56CH
Sensitivity: tracking -162dBm; Acquisition: 160dBm; cold start: -148dBm
Cold Start: 29s average
Warm Start: 3s average
Hot Start: 1s average
Accuracy: horizontal position accuracy<2.5M, SBAS<2.0M
Timing Accuracy: 30ns
Update Rate: 1Hz
Outline Dimension: 60×24×9mm
Weight: 50g
Operating Temperature: -40°C~85°C
Storage Temperature: -40°C~85°C

Documents:

Product wiki

Shipping List:

USB GPS Receiver x1

This product is listed in:

Wireless>GPS>Modules
