SparkFun Capacitive Touch Slider - CAP1203 (Qwiic)

SKU: SEN-15344 Brand: Sparkfun

Do you want to replace a slider or a button on your art project or science experiment with a more interesting interface? This Capacitive Touch Slider is a "Qwiic"...

$13.60 AUD, inc GST

$12.36 AUD, exc GST

Available with a lead time
Expect dispatch between May 19 and May 21

Quantity Discounts:

10+ $11.99 (exc GST)
25+ $11.75 (exc GST)

Do you want to replace a slider or a button on your art project or science experiment with a more interesting interface? This Capacitive Touch Slider is a "Qwiic" and easy way to add capacitive touch to your next project. With the board's built in touch pads, you can immediately start playing with the touch capabilities as three unique touch inputs or as a slider. You can also enable a touch input to act as a power button, customize the sensitivity for your own touch pads, and play with the interrupt alert LED. Utilizing our Qwiic system, no soldering is required to connect it to the rest of your system. However, Sparkfun have broken out 0.1"-spaced pins in case you prefer to use a breadboard or create your own touch pads.

On the front of the board, there is an arrow shape which contains three separate capacitive touch pads. Sparkfun also broke out the capacitive touch sensor lines as plated through-holes on the top of the board. You can use these pins to connect to your own capacitive touch pads. The CS1 pin connects to the left pad, the CS2 pin connects to the middle pad, and the CS3 pin connects to the right pad.

The SparkFun Qwiic connect system is an ecosystem of I²C sensors, actuators, shields and cables that make prototyping faster and less prone to error. All Qwiic-enabled boards use a common 1mm pitch, 4-pin JST connector. This reduces the amount of required PCB space, and polarized connections mean you can't hook it up wrong.

Get Started with the SparkFun Capacitive Touch Slider Guide

Features

Capacitive Touch
- 3 unique capacitive touch inputs
Features
- Emulated slider
- Power button setting
- Programmable sensitivity
- Automatic recalibration
- I²C Address: 0x28
- Qwiic Enabled
Operating Range
- Supply Voltage: 3.3V - 5V
