M5Atom Joystick with M5AtomS3

SKU: CE09943 Brand: M5Stack

Hall-effect thumbsticks, a built-in screen and a rechargeable battery in one handheld controller, ready to pair out of the box.

$88.86 AUD, inc GST
$80.78 AUD, exc GST

Out of Stock

Sign up to get notified when it's available to order.

Shipping:

  • $7+ Standard (5+ days*, tracked)
  • $11+ Express (2+ days*, tracked)
  • FREE Pickup (Newcastle only - must order online*)

Shipping costs may increase for heavy products or large orders.

Exact shipping can be calculated on the view cart page.

*Conditions apply, see shipping tab below.

A handheld remote controller for the StampFly v1.1 drone (sold separately). It comes pre-flashed with StampFly remote-control firmware and pairs over ESP-NOW. The firmware is open source, so you can rework the same hardware to steer robots, smart cars and other DIY builds.

This v1.1 revision replaces the original AtomS3 controller with the AtomS3R. It adds 8MB of PSRAM alongside the 8MB Flash, replaces the MPU6886 IMU with a BMI270 6-axis sensor, adds a BMM150 3-axis magnetometer and upgrades to an enhanced 3D antenna. The STM32F030F4P6 co-processor in the base is unchanged.

Charge the battery through the USB-C port on the base, because the AtomS3R's own USB-C port does not charge it. The indicator shows red while charging and green when full. For battery care, never discharge it below 3V under load, don't leave it fully charged for more than 3 days, and store it at 3.8 to 3.9V long term.

Features

  • Control two axes plus a click under each thumb with two Hall-effect five-way joysticks, backed by two function buttons and an independent power switch.
  • Show your own status screens and menus on the AtomS3R's 0.85" 128 x 128 LCD, right between the sticks.
  • Get feedback without looking at the screen through the onboard buzzer, two RGB LED indicators and built-in battery voltage detection.
  • Top up your StampFly v1.1 batteries between flights using the controller's two onboard charging sockets (CH1 and CH2).
  • Spend less time waiting on the charger: the controller's included 320mAh battery fully charges in about 55 minutes.

Specifications

Property Specification
Controller AtomS3R
SoC ESP32-S3-PICO-1-N8R8, Xtensa 32-bit LX7 dual-core, up to 240MHz
Memory 8MB Flash, 8MB Octal PSRAM
Wireless 2.4GHz Wi-Fi (ESP-NOW link to StampFly)
Display 0.85" LCD, 128 x 128
6-axis IMU BMI270 (I2C 0x68)
Magnetometer BMM150, 3-axis
Inputs 2x Hall-effect five-way joysticks, 2x function buttons, 1x power switch
Base co-processor STM32F030F4P6
Base interface I2C @ 0x59 (AtomS3R G38 SDA, G39 SCL)
RGB LEDs 2x WS2812C (G6)
Buzzer Onboard 5020 passive buzzer (G5)
Charging chip TP4067 @ 4.35V
Battery 320mAh 1S LiHV, 4.35V output; charging DC 5V @ 430mA
Full charge time (included battery) Approx. 55 minutes
Battery connectors 2x BT2.0 male power terminals
Operating temperature 0 to 40°C
Dimensions 84.0 x 60.0 x 31.5mm
Weight 56.2g (excluding battery)

Resources

What's included

  • 1x Atom JoyStick v1.1 base with AtomS3R controller
  • 1x 320mAh LiHV battery
