Keep your Pi 5 cool, good-looking and protected with this dual-fan case!
In stock, ships same business day if ordered before 2PM
Fastest delivery: Tomorrow*
Disclaimer:
For next-day delivery, the shipping address must
be in the AusPost next-day network, eParcel Express must be selected, and the order must be placed
before 2PM AEST Mon-Thurs excluding NSW Public Holidays. Orders may be delayed due to AusPost
pickup timings and order verifications. eParcel Express is typically a 1-day service within the
AusPost next-day network, though it is sometimes 2+ days.
Give your Raspberry Pi 5 the a way to keep itself cool along with the rock-solid protection it deserves. Machined from aluminium, this two-part enclosure turns the entire case into a heatsink THEN added two fans to actively blow air over the hottest parts of the board.
A passive and single-fan edition is also available for those who like their Pi quieter.
CNC-milled aluminium top & bottom shell – tough, lightweight
Dual fans – Actively push air across the fins of the heatsink, the fans connect easily through the Pi 5's fan connector
Pre-cut thermal pads – create a direct thermal bridge from the Pi 5’s CPU (and RAM if you wish) to the case
Hex bolts + hex key – for quick, secure assembly
Full access to every port, pin-header and connector on the Raspberry Pi 5
Compatible with Raspberry Pi 5 only
Power down & unplug your Pi 5.
Apply thermal pad: peel both films and place the pad on the CPU. Add a second pad on the RAM and other ICs if you’d like extra coverage.
Sandwich the board: align the top shell (fins up) over the CPU, position the bottom shell beneath the board, and hold together.
Bolt it up with the supplied hex screws.
Because the case hugs the Pi, standard HATs will need 2×20 header extenders or a ribbon cable to clear the case.
The enclosure conducts heat and electricity – watch for accidental shorts when wiring up external circuits.
The fans
