Search results for: 'micro dc geared motor'

This is the DFRobot Micro DC geared motor with encoder. It is a motor with a 120:1 gearbox and an integrated quadrature encoder that provides a resolution of 16 pulse single per round giving a maximum output of 1920 within one round. With an Arduino controller and motor driver, applications for this include a closed-loop PID control or PWM motor speed control. This motor is an ideal option for mobile robot projects. The copper output shaft, embedded thread and reinforced connector greatly extends the motor's service life.

This DC gearmotor has an integrated M4*55mm threaded rod as its output shaft, turn it into a linear actuator. 6V rated voltage, the no-load speed could arrive 150RPM, equivalent to 1.75mm/s. The brass faceplate has two mounting holes threaded for M1.6 screws (1.6mm diameter, 0.35mm thread pitch), or you can use the mounting bracket or extended mounting bracket, which are specifically designed to securely mount the gear motor while enclosing the exposed gears.

The 6V, 180rpm Micro DC Geared Motor with Back Shaft is ideal for DIY enthusiasts and is designed to easily incorporate the DFRobot Encoder. These motors are inexpensive, small, easy to install, and ideally suited for use in a mobile robot car. The DFRobot RoMeo microcontroller (sold separately) is able to complete the closed-loop PID making use of theoptional encoders.

This motor has a long (0.365" or 9.27 mm), D-shaped metal output shaft that matches the Pololu wheel 42x19mm and 32x7mm. The brass faceplate has two mounting holes...

This is a new micro DC geared motor, using planetary gear mechanism, applicable to the various types of DIY project. Especially the project which has a certain requirements for size. It will be a good partner for you.

This DC gearmotor has an integrated M3*25mm long rod as its output shaft, turn it into a linear actuator. 6V rated voltage, the no-load speed could arrive 98RPM...

This is the DFRobot Micro DC geared motor with encoder. It is a motor with a 120:1 gearbox and an integrated quadrature encoder that provides a resolution of 16 pulse single per round giving a maximum output of 1920 within one round. With an Arduino controller and motor driver, applications for this include a closed-loop PID control or PWM motor speed control. This motor is an ideal option for mobile robot projects. The copper output shaft, embedded thread and reinforced connector greatly extends the motor's service life.

An ordinary DC motor requires an H Bridge to work with a microcontroller such as an UNO. For newcomers to electronics, the process of finding the right motor driver, connecting it to the MCU and learning the relevant electronic theory can be confusing and frustrating when you just need something to work quickly. We hope that using the DC Micro Metal gear motor changes this.

An ordinary DC motor requires an H Bridge to work with a microcontroller such as an UNO. For newcomers to electronics, the process of finding the right motor driver, connecting it to the MCU and learning the relevant electronic theory can be confusing and frustrating when you just need something to work quickly. We hope that using the DC Micro Metal gear motor changes this.

This is a miniature stepper motor with 100:1 metal reduction gear box for enhanced torque. It has a voltage input range of 5 - 12V DC. This product is suitable for the 3D printers and applications which require precise rotation control.

The Klip Motor Driver for BBC microbit allows you do more than just drive motors. It breaks out pins 0, 1, 2, 3V & GND from the microbit & connects to ZIP LEDS.

This is a great first stepper motor, good for small projects and experimenting with steppers. This uni-polar motor has a built in mounting plate with two mounting...

This is a great first stepper motor, good for small projects and experimenting with steppers. This uni-polar motor has a built in mounting plate with two mounting...

This gearmotor is a miniature (0.94" x 0.39" x 0.47"), low-current brushed DC motor with 297.92:1 metal gearbox, similar to Sanyo’s popular 12 mm gearmotors. These units have a 0.365"-long, 3 mm-diameter D-shaped output shaft. This version also has a 4.5 x 1 mm extended motor shaft. Key specs at 6 V: 45 RPM and 30 mA free-run, 40 oz-in (2.9 kg-cm) and 0.36 A stall.

This gearmotor is a miniature (0.94" x 0.39" x 0.47"), high-quality, high-power motor with 9.96:1 metal gearbox, similar to Sanyo’s popular 12 mm gearmotors. These units have a 0.365"-long, 3 mm-diameter D-shaped output shaft. This version also has a 4.5 x 1 mm extended motor shaft. Key specs at 6 V: 3000 RPM and 120 mA free-run, 4 oz-in (0.3 kg-cm) and 1.6 A stall.

This gearmotor is a miniature low-power, 6 V brushed DC motor with a 9.96:1 metal gearbox. It has a cross section of 10 × 12 mm, and the D-shaped gearbox...

This gearmotor is a miniature low-power, 6 V brushed DC motor with a 379.17:1 metal gearbox. This version has stainless steel gearbox plates instead of...

This gearmotor is a miniature medium-power, 6 V brushed DC motor with a 4.995:1 metal gearbox. It has a cross section of 10 × 12 mm, and the D-shaped...

This gearmotor is a miniature (0.94" x 0.39" x 0.47"), high-power brushed DC motor with 100.37:1 metal gearbox, similar to Sanyo’s popular 12 mm gearmotors. These units have a 0.365"-long, 3 mm-diameter D-shaped output shaft. This version also has a 4.5 x 1 mm extended motor shaft. Key specs at 6 V: 320 RPM and 80 mA free-run, 30 oz-in (2.2 kg-cm) and 1.6 A stall.

This gearmotor is a miniature (0.94" x 0.39" x 0.47") brushed DC motor with 100.37:1 metal gearbox, similar to Sanyo’s popular 12 mm gearmotors. These units have a 0.365"-long, 3 mm-diameter D-shaped output shaft. This version also has a 4.5 x 1 mm extended motor shaft. Key specs at 6 V: 220 RPM and 40 mA free-run, 19 oz-in (1.4 kg-cm) and 0.7 A stall.

This gearmotor is a miniature medium-power, 6 V brushed DC motor with a 248.98:1 metal gearbox. It has a cross section of 10 × 12 mm, and the D-shaped...

These are typical rubber wheels for small robot mobile platforms. The tire is soft black rubber with light tread for added traction in rugged terrain.

This gearmotor is a miniature high-power, 6 V brushed DC motor with long-life carbon brushes and a 15.25:1 metal gearbox. It has a cross section of...

This is a miniature brushed DC metal gearmotor with a gearbox cross section of 10×12 mm and a 9 mm long, 3 mm diameter D-shaped gearbox output shaft....

These are typical rubber wheels for small robot mobile platforms. The tire is soft black rubber with light tread for added traction in rugged terrain.

This gearmotor is a miniature medium-power, 6 V brushed DC motor with a 29.86:1 metal gearbox. It has a cross section of 10 × 12 mm, and the D-shaped...

This gearmotor is a miniature (0.94" x 0.39" x 0.47"), high-power brushed DC motor with 75.81:1 metal gearbox, similar to Sanyo’s popular 12 mm gearmotors. These units have a 0.365"-long, 3 mm-diameter D-shaped output shaft. This version also has a 4.5 x 1 mm extended motor shaft. Key specs at 6 V: 400 RPM and 70 mA free-run, 22 oz-in (1.6 kg-cm) and 1.6 A stall.

This gearmotor is a miniature high-power, 6 V brushed DC motor with long-life carbon brushes and a 4.995:1 metal gearbox. It has a cross section of...

This gearmotor is a miniature low-power, 6 V brushed DC motor with a 248.98:1 metal gearbox. It has a cross section of 10 × 12 mm, and the D-shaped...

This gearmotor is a miniature low-power, 6 V brushed DC motor with a 986.41:1 metal gearbox, making it a great choice for applications requiring fine...

This gearmotor is a miniature medium-power, 6 V brushed DC motor with a 51.45:1 metal gearbox. It has a cross section of 10 × 12 mm, and the D-shaped...

This gearmotor is a miniature high-power, 6 V brushed DC motor with long-life carbon brushes and a 210.59:1 metal gearbox. It has a cross section of...

This gearmotor is a miniature (0.94" x 0.39" x 0.47"), high-power brushed DC motor with 51.45:1 metal gearbox, similar to Sanyo’s popular 12 mm gearmotors. These units have a 0.365"-long, 3 mm-diameter D-shaped output shaft. This version also has a 4.5 x 1 mm extended motor shaft. Key specs at 6 V: 625 RPM and 100 mA free-run, 15 oz-in (1.1 kg-cm) and 1.6 A stall.

This gearmotor is a miniature medium-power, 6 V brushed DC motor with a 986.41:1 metal gearbox, making it a great choice for applications requiring fine...

This gearmotor is a miniature medium-power, 6 V brushed DC motor with a 210.59:1 metal gearbox. It has a cross section of 10 × 12 mm, and the D-shaped...

This gearmotor is a miniature high-power, 6 V brushed DC motor with long-life carbon brushes and a 100.37:1 metal gearbox. It has a cross section of...

This gearmotor is a miniature medium-power, 6 V brushed DC motor with a 15.25:1 metal gearbox. It has a cross section of 10 × 12 mm, and the D-shaped...

This gearmotor is a miniature high-power, 6 V brushed DC motor with long-life carbon brushes and a 986.41:1 metal gearbox, making it a great choice for...
