Arduino Uno Q - 4GB

SKU: ABX00173 Brand: Arduino

Combining a high-performance Linux CPU with real-time control - capable of running modern tasks such as machine vision, voice recognition. This model packs 4GB of RAM for more resource intensive models!

$124.95 AUD, inc GST

$113.59 AUD, exc GST

Out of Stock

Meet Arduino UNO Q, a dual-processor development board that pairs a Linux Debian computer with a real-time microcontroller. Prototype robots, edge AI, or connected IoT devices on a single, unified platform that lets sketches and Python live side by side via the Arduino App Lab.

Scale ideas fast with the onboard CPU - a Qualcomm Dragonwing QRB2210 microprocessor for AI vision and audio, plus an STM32U585 microcontroller for deterministic control. It works with classic UNO shields, new carriers, and Modulino/Qwiic/PiicoDev modules for rapid prototyping.

We also have a listing for the Uno Q 2GB.

Technical Specifications

Microprocessor	Qualcomm Dragonwing™ QRB2210: Quad-core Arm® Cortex®-A53 @ 2.0 GHz Adreno GPU 3D graphics accelerator 2x ISP (13 MP + 13 MP or 25 MP) @ 30 fps
Microcontroller	STM32U585 Arm® Cortex®-M33 up to 160 MHz 2 MB flash memory 786 KB SRAM
Memory	4 GB LPDDR4
Storage	16 GB eMMC (no SD card required)
Interfaces and IO	I2C/I3C SPI PWM CAN UART PSSI GPIO JTAG ADC 4× RGB user-controllable LEDs 8x13 Blue LED Matrix 1x Qwiic connector voltage 3V3, I2C 1x User push-button JCTL: MPU Remote Debug connector
Video	Video output supported through USB-C MIPI (DSI) pins via JMEDIA header
Audio	Microphone IN / Headphone OUT / Line OUT on JMISC
Wireless	Wi-Fi 5 dual band 2.4 GHz and 5 GHz, Bluetooth 5.1
Connectors	Classic UNO headers, high-speed headers for vision, audio, display; Qwiic connector
USB-C	Power delivery, video output, and support for USB peripherals via a dongle
On-board display	8 x 13 LED matrix
AI-ready examples	Object and human detection, anomaly detection, image classification, sound recognition, keyword spotting
Operating System/Software stack	Linux Debian OS with upstream support Arduino Core on Zephyr OS Containerisation via Docker
Dimensions	68.85 mm x 53.34 mm (UNO form factor)
