7 Segment Display (2-Wire, 0.5")

Rating:
100% of 100
SKU: CE09446 Brand: Core Electronics

Perfect for when you need to display the time or some simple sensor read-outs, all with two pins!

$1.95 AUD, inc GST
$1.77 AUD, exc GST

In stock, ships same business day if ordered before 2PM
Delivered by Tue, 26th of Nov

Quantity Discounts:

  • 5-15 $1.74 (exc GST)
  • 15+ $1.68 (exc GST)
- +

34 from local stock, 1 supplier stock; your order will dispatch between Dec 1 to Dec 10. And yes, stock levels and lead times are accurate!

Shipping:

  • $7+ Standard (5+ days*, tracked)
  • $11+ Express (2+ days*, tracked)
  • FREE Pickup (Newcastle only - must order online*)

Shipping costs may increase for heavy products or large orders.

Exact shipping can be calculated on the view cart page.

*Conditions apply, see shipping tab below.

Perfect for when you need to display the time or some simple sensor read-outs.

Includes M2 37mm x 20mm mounting holes to make mounting and viewing easy.

Note: Even though this sensor uses data and clock it is NOT I2C or SPI, seperate pins are required and a proprietary library is below.

Specifications

  • Uses the TM1637 chipset to drive the 7-segment Display
  • 3.3-5V Logic and Power input
  • Display size: 30mm x 14mm (0.5")
  • Ships with pre-soldered right-angle headers

Resources

Examples

Raspberry Pi Pico - Micropython

Library: https://github.com/mcauser/micropython-tm1637

from machine import Pin
import utime
import tm1637

# Define pins for TM1637 display module
TM1637_CLK_PIN = 2
TM1637_DIO_PIN = 3

# Initialize TM1637 display object
tm = tm1637.TM1637(clk=Pin(TM1637_CLK_PIN), dio=Pin(TM1637_DIO_PIN))

# Loop to display a count on the TM1637 display
count = 0
while True:
    count_padded = f'{count:04}'  # Add leading zeros to the number
    tm.show(count_padded)  # Update the display with the number
    count += 1
    utime.sleep(1)
