6-Pin Female-Female JST SH-Style Cable 16cm

SKU: POLOLU-4766 Brand: Pololu

This 16 cm (6.3") cable has six 28 AWG wires and 6-pin female JST SH-type connectors on both ends. These connectors work with our Micro Metal Gearmotor ...

$4.05 AUD, inc GST

$3.68 AUD, exc GST

Available with a lead time
Expect dispatch between Dec 30 and Jan 02

Quantity Discounts:

10-25 $3.54 (exc GST)
25+ $3.43 (exc GST)

This cable is designed to work with Pololu's Micro Metal Gearmotor Encoders with top-entry connector and with side-entry connector. It consists of six twisted 28 AWG color-coded wires that are terminated on both ends by female JST SH-type connectors.

You can use the cable to connect an encoder to Pololu's JST SH-style connector breakout board (available in top-entry and side-entry versions), allowing you to easily access the motor and encoder pins on a standard solderless breadboard. Alternatively, a cable with two connector breakout boards could serve as a removable general-purpose interconnect between different parts of a modular system.

Use with Micro Metal Gearmotor Encoders

When used with Pololu's encoders, the wire color scheme is as follows:

Color	Function
Red	motor power (connects to one motor terminal)
Black	motor power (connects to the other motor terminal)
Blue	encoder Vcc
Yellow	encoder A output
White	encoder B output
Green	encoder GND

For more information on how to use the encoders, see the encoder product pages.

Available options

Pololu's female-female cables are available in five lengths:

Pololu also have single-ended cables, with a female JST SH-style connector on one end and unterminated wires on the other end, available in three cable lengths:

People often buy this product together with:

Magnetic Encoder Pair Kit with Top-Entry Connector for Micro Metal Gearmotors, 12 CPR, 2.7-18V

6-Pin Female-Female JST SH-Style Cable 10cm

Breakout for JST SH-Style Connector, 6-Pin Male Top-Entry (3-Pack, Untested)

Dimensions

Pins:	1×6
Length:	16 cm
Weight:	2 g

General specifications

Gender:	Female-Female
Wire gauge:	28 AWG
Connector:	JST SH-type
