Sense HAT for Raspberry Pi Zero

SKU: WS-23229-1 Brand: Waveshare

Explore the Waveshare Sense HAT for Raspberry Pi Zero, featuring onboard environmental sensors and expandable I/O capabilities for your next DIY electronics project.

$38.70 AUD, inc GST
$35.18 AUD, exc GST

In stock, ships same business day if ordered before 2PM
Delivered by Tue, 28th of Oct

Quantity Discounts:

  • 10+ $33.77 (exc GST)
  • 25+ $32.72 (exc GST)
- +

2 from local stock, 1 supplier stock; your order will dispatch between Dec 1 to Dec 10. And yes, stock levels and lead times are accurate!

Shipping:

  • $7+ Standard (5+ days*, tracked)
  • $11+ Express (2+ days*, tracked)
  • FREE Pickup (Newcastle only - must order online*)

Shipping costs may increase for heavy products or large orders.

Exact shipping can be calculated on the view cart page.

*Conditions apply, see shipping tab below.

The Waveshare Sense HAT for Raspberry Pi Zero is a compact, feature-rich expansion board that transforms any Raspberry Pi Zero into a versatile environmental monitoring and motion sensing platform. This HAT combines multiple high-precision sensors with expandable I/O capabilities, making it ideal for developing prototypes, creating educational demonstrations, or building sophisticated environmental monitoring solutions.

Specifications

QMI8658C Motion Sensor

  • 3-axis accelerometer and 3-axis gyroscope

  • I2C Address: 0x6B

  • Accelerometer:

    • Resolution: 16-bit

    • Measurement Range (configurable): ±2, ±4, ±8, ±16 g

  • Gyroscope:

    • Resolution: 16-bit

    • Measurement Range (configurable): ±16, ±32, ±64, ±128, ±256, ±512, ±1024, ±2048 °/sec

AK09918 Magnetometer

  • 3-axis magnetometer

  • I2C Address: 0x0C

  • Resolution: 16-bit

  • Measurement Range (configurable): ±4912 µT

SHTC3 Temperature & Humidity Sensor

  • I2C Address: 0x70

  • Temperature Range: -30°C to 100°C (Accuracy: ±0.2°C)

  • Humidity Range: 0% to 100% RH (Accuracy: ±2% RH)

LPS22HB Barometric Pressure Sensor

  • I2C Address: 0x5C

  • Measurement Range: 260 to 1260 hPa

  • Accuracy (ordinary temperature): ±0.025 hPa

  • Sampling Speed: 1 Hz to 75 Hz

SGM58031 ADC Converter

  • I2C Address: 0x48

  • Channels: 4

  • Resolution / Accuracy: 16-bit

TCS34087 Color Sensor

  • I2C Address: 0x29

  • Gain Ratios: 0.5×, 1×, 2×, 4×, 8×, 16×, 32×, 64×, 256×, 512×, 1024×, 2048×

What's Onboard

  1. Raspberry Pi GPIO Header - for connecting with Raspberry Pi
  2. Sensor Interface - for external sensors
  3. I2C Extension Header - for connecting with host boards like STM32
  4. AK09918 - 3-axis magnetometer
  5. QMI8658C - 6-axis motion sensor
  6. SHTC3 - Temperature and humidity sensor
  7. LPS22HB - Barometric pressure sensor
  8. TCS34725 - Colour sensor
  9. SGM58031 - 16-bit ADC
  10. LSF0204PWR- 4-ch voltage level translator
  11. RT9193-33 - 3.3V linear regulator
  12. RT9193-18 - 1.8V linear regulator


Dimensions

Resources

What's in the Box

  • 1 x Waveshare Sense HAT for Raspberry Pi Zero
  • 1 x Mounting hardware
