Search results for: 'jst'
- JST 2-pin cableRed and black tinned wires with a 2-pin JST PH connector on the end. 4" / 100mm long. Matches up nicely with Adafruit's Lipoly charger! Adafruit don't have the 'mating' version...
- JST 2-pin Extension Cable with On/Off Switch - JST PH2SKU: ADA3064 Brand: AdafruitBy popular request - Adafruit now have a way you can turn on-and-off Lithium Polymer batteries without unplugging them. This PH2 Female/Male JST 2-pin Extension Cable...
- JST PH Cable (3-Pos JST PH, MH-FC to MH-FC, 300mm Length)SKU: GB-3804-5454-0300 Brand: goBildaLet there be lights…that are linked to one another! When your build needs a legion of lumens, a JST extension (like this 300mm length.....
- JST PH Cable (4-Pos JST PH, MH-FC to MH-FC, 600mm Length)SKU: GB-3804-0707-0600 Brand: goBildaThis 600mm length 4-Pos JST cable has female connectors at both ends for conveying data between electronics in your project. It is the same.....
- JST connector Kit (2.54mm)This kit includes JST XHP-2, XHP-3 and XHP-4 housing (20 units each), through-hole type shrouded header (20 units each) and crimp contact (100 units).
- 4-Pos JST PH [MH-FC] to 4-Pos JST XH [MH-FC] Adaptor (150mm Length)SKU: GB-3801-0709-0150 Brand: goBildaThis 150mm Length JST adaptor is able to plug into the encoder found on 5000 Series Motors and 52xx Series Gear Motors, using the JST XH.....
- 4-Pos JST PH [MH-FC] to 4-Pos JST XH [MH-FC] Adaptor (600mm Length)SKU: GB-3801-0709-0600 Brand: goBildaThis 600mm Length JST adaptor is able to plug into the encoder found on 5000 Series Motors and 52xx Series Gear Motors, using the JST XH.....
- 4-Pos JST PH [MH-FC] to 4-Pos JST XH [MH-FC] Adaptor (300mm Length)SKU: GB-3801-0709-0300 Brand: goBildaThis 300mm Length JST adaptor is able to plug into the encoder found on 5000 Series Motors and 52xx Series Gear Motors, using the JST XH Series end.
- PIR Motion Sensor (JST)SKU: SEN-13285 Brand: SparkfunThis is a simple to use motion sensor. Power it up and wait 1-2 seconds for the sensor to get a snapshot of the still room. If anything moves after that period, the ‘alarm’ pin will go low.
- JST connector Kit (2.0mm)SKU: FIT0299 Brand: DFRobotThis kit includes PHR-2，PHR-3 and PHR-4 housing (20 units each)， through-hole type shrouded header （20 units each）and crimp contact (100 units).
- SparkFun JST Battery Removal ToolSKU: TOL-27923 Brand: SparkfunThe SparkFun JST battery removal tool is a tool to remove a standard 2-pin JST-PH connector (2mm pitch) from its housing! Use the JST battery removal tool...
- JST PH to Breadboard Jumper (3-pin)SKU: CAB-13685 Brand: SparkfunThis is a simple jumper adapter cable that comes pre-terminated with a female JST connector on one end and a breadboard hookup pigtail on the other. This cable makes it easy to connect components with a JST connector to a breadboard or an Arduino-based device’s pins.
- JST RCY Connector Pack, FemaleSKU: POLOLU-1934 Brand: PololuThis JST RCY plug is also referred to as a BEC (battery eliminator circuit) connector and is commonly used with battery packs for RC applications. The connector is keyed so that power cannot be reversed. You can use a crimping tool to attach these connectors to your own 22- to 28-AWG wires. This pack contains enough housings and crimp pins (including two spare pins) for 3 female connectors.
- JST RCY Connector Pack, MaleSKU: POLOLU-1935 Brand: PololuThis JST RCY plug is also referred to as a BEC (battery eliminator circuit) connector and is commonly used with battery packs for RC applications. The connector is keyed so that power cannot be reversed. You can use a crimping tool to attach these connectors to your own 22- to 28-AWG wires. This pack contains enough housings and crimp pins (including two spare pins) for 3 male connectors.
- JST 4 Holes Female ConnectorSKU: FIT0150 Brand: DFRobotThis product includes 4-pin 2.0mm mating connector housing(10 units) and crimp pins (40 units).
- 4-pin JST PH to JST SH Cable - STEMMA to QT / Qwiic - 200mm longSKU: ADA4424 Brand: AdafruitAre you a maker in the midst of a STEMMA dilemma? This 200mm long 4-wire cable is a fantastic chimera-cable fitted with STEMMA QT / Sparkfun Qwiic JST SH on one...
- JST Right-Angle Connector - Through-Hole 2-PinSKU: PRT-09749 Brand: SparkfunThis is a 2-pin, through-hole PH series JST connector. The pins are spaced by 2mm.
- Barrel Jack to 2-pin JST PH 2mmSKU: TOL-08734 Brand: Sparkfun
Two pin JST PH 2mm connector to a 2.1x 5.5mm barrel jack, 6.25 inch long jumper cable. We use this cable to adapt from a wall power supply to a relatively small, SMD JST connector. We found that many of the SMD connectors used for battery charging were too large or were not capable of through-putting the current we wanted for faster charging. This setup, with a SMD JST connector and wall power supply, can handle up to 2A!
- JST SH-Style Cable, 4-Pin, Female-Female, 63cmSKU: POLOLU-5527 Brand: PololuThis 4-conductor, 63 cm (25") cable has 28 AWG wires and 4-pin female JST SH-type connectors on both ends...
- JST SH-Style Cable, 2-Pin, Female-Female, 25cmSKU: POLOLU-5505 Brand: PololuThis 2-conductor, 25 cm (10") cable has 28 AWG wires and 2-pin female JST SH-type connectors on both ends...
- JST SH-Style Cable, 2-Pin, Female-Female, 10cmSKU: POLOLU-5503 Brand: PololuThis 2-conductor, 10 cm (4") cable has 28 AWG wires and 2-pin female JST SH-type connectors on both ends...
- JST PH-Style Cable, 6-Pin, Female-Female, 10cmSKU: POLOLU-5643 Brand: PololuThis 6-conductor, 10 cm (4") cable has 24 AWG wires and 6-pin female JST PH-type connectors (2mm pitch) on both ends...$5.40 AUD, inc GSTAvailable with 4 to 7 day lead time
- JST PH-Style Cable, 5-Pin, Female-Female, 10cmSKU: POLOLU-5633 Brand: PololuThis 5-conductor, 10 cm (4") cable has 24 AWG wires and 5-pin female JST PH-type connectors (2mm pitch) on both ends...
- JST PH-Style Cable, 4-Pin, Female-Female, 63cmSKU: POLOLU-5627 Brand: PololuThis 4-conductor, 63 cm (25") cable has 24 AWG wires and 4-pin female JST PH-type connectors (2mm pitch) on both ends...$7.10 AUD, inc GSTAvailable with 4 to 7 day lead time
- JST PH-Style Cable, 3-Pin, Female-Female, 10cmSKU: POLOLU-5613 Brand: PololuThis 3-conductor, 10 cm (4") cable has 24 AWG wires and 3-pin female JST PH-type connectors (2mm pitch) on both ends...$2.95 AUD, inc GSTAvailable with 4 to 7 day lead time
