Breakout for JST PH-Style Connector, 2-Pin Male Top-Entry, with SH

SKU: POLOLU-5650 Brand: Pololu

This simple board serves as an adapter between a JST PH-style 2-pin, top-entry connector and breadboard-compatible 0.1"-pitch through holes. The PH...

Special Price $2.20 AUD, inc GST

Regular Price $2.70 AUD, inc GST

$2.00 AUD, exc GST

Special pricing ends 14 December 2025

* this special may end earlier than shown

Available with a lead time
Expect dispatch between Dec 15 and Dec 18

Details for item #5650

This product is a JST PH-style connector adapter board with a 2-pin, top-entry connector.

Pololu have various cables that work with the 2mm-pitch JST PH-style connector on this breakout board, available in double-sided or single-sided versions of varying lengths. The double-sided versions have twisted wires and female JST PH-type connectors on both ends, and single-sided versions have a female connector on one end female crimp pins for 0.1" housings on the other:

JST PH-Style 2-Pin Cables
Pins	Terminations	Length	Item #


2	double-sided (JST PH to JST PH)	10 cm (4")	#5603
		16 cm (6.3")	#5604
		25 cm (10")	#5605
		40 cm (16")	#5606
		63 cm (25")	#5607
	single-sided (JST PH to 0.1" crimp pins)	12 cm (4.5")	#5600
		30 cm (12")	#5601
		75 cm (30")	#5602

This board also includes a smaller (1mm-pitch), 2-pin, top-entry JST SH-style connector in parallel with the PH-style connector, offering an additional connection option for your project. The inclusion of both connectors also enables the board to be used as a PH-to-SH adapter. The following cables are compatible with the JST SH-style connector:

JST SH-Style 2-Pin Cables
Pins	Terminations	Length	Item #


2	double-sided (female-female)	10 cm (4")	#5503
		16 cm (6.3")	#5504
		25 cm (10")	#5505
		40 cm (16")	#5506
		63 cm (25")	#5507
	single-sided (female-unterminated)	12 cm (4.5")	#5500
		30 cm (12")	#5501
		75 cm (30")	#5502

Breakout for JST PH-style connector family overview

Pololu's JST PH-type connector breakout boards provide access to each pin on a row of 0.1"-pitch through holes, making them compatible with standard solderless breadboards. They are available in a variety of pin counts and connector styles:

Top entry	Side entry


2-pin



3-pin



4-pin



5-pin



6-pin

The larger, 2mm-pitch JST PH-style connectors are rated for up to 2 A per pin and are compatible with Pololu's female JST PH-style cables. The smaller, 1mm-pitch JST SH-style connectors are rated for up to 1 A per pin and are compatible with Pololu's female JST SH-style cables. The boards can serve as breakouts for either connector, or they can serve as JST PH to SH adapters if both are used at the same time. (Note: Pololu also have smaller breakout boards with just the JST SH-style connector for applications where PH connectivity is not required.)

Breakout boards for JST PH-style connectors can be used as JST PH to JST SH adapters.

The through-holes work with standard 0.1" (2.54 mm) male headers and 0.1" female headers as well as with Pololu's 0.1" screw terminal blocks, all of which are available separately:

Breakout boards for JST PH-style connectors in a breadboard.

Breakout boards for JST PH-style connectors are compatible with Pololu’s 0.1" terminal blocks.

Dimensions

Size:	0.73" × 0.38" × 0.3"
Pins:	2
Weight:	0.6 g

General specifications

Current rating:	2 A¹
Voltage rating:	50 V
Connector:	top-entry, JST PH-type (2.0 mm pitch)²

Identifying markings

PCB dev codes:	con08a
Other PCB markings:	0J15755

Notes:

1: Note: The smaller SH connector is only rated for 1A per pin.
2: Board also includes a top-entry JST SH-style (1.0 mm pitch) connector.

File downloads

Dimension diagram for the JST PH-Style Connector Boards (2MB pdf)
3D models of the JST PH-Style Connector Boards (7MB zip)
This file contains 3D models (in the step file format) of the JST PH-Style Connector Boards.
Drill guides for the JST PH-Style Connector Boards (10k zip)
These DXF drawings show the locations of all of the holes for boards con08a, con09a, con10a, con11a, and con12a.
