MG Chemicals 419C Acrylic Conformal Coating II - 55ML

SKU: CE05761

$19.25 AUD, inc GST
$17.50 AUD, exc GST
MG Chemicals 419C Acrylic Conformal Coating II - 55ML
19.25 AUD

SKU: CE05761

$19.25 AUD, inc GST
$17.50 AUD, exc GST

Shipping:

  • $6.95 Standard (2-4 days, tracked)
  • $9.95 Express (Overnight*, tracked)
  • $3 Economy Post* (3-7 days, no tracking)
  • FREE Pickup (Newcastle only)

Shipping costs may increase for heavy products or large orders.

Exact shipping can be calculated on the view cart page.

*Conditions apply, see shipping tab below.

MG Chemicals 419C Acrylic Conformal Coating is an IPC 830 certified, fast drying, xylene and toluene free product that provides an excellent finish. This one part coating is easy to use and does not require special or costly equipment to apply. It is ideal for high moisture environments and applications requiring easy repair and rework.

The 419C coating protects the electric circuit against moisture, dirt, dust, thermal shocks, and scratches that could corrode, short circuit, or otherwise damage the electric component. It insulates against high-voltage arcing, shorts, and static discharges. As well as, this coating provides a high dielectric withstand voltage that allows traces to be put closer together helping with miniaturization.

Features

  • Super fast cure — reduces production and maintenance bottlenecks.
  • No Hazardous Air Pollutants — free of toluene and xylene
  • Externally Qualified to IPC-CC-830B by Pacific Testing Laboratories, Inc.
  • UL Recognized for Flame Class 94 V-0 (E202094)
  • Excellent finish — smooth, homogeneous, and durable crystal clear coat
  • Protects electronics from moisture, corrosion, fungus, and static discharges
  • Easy to inspect — fluoresces under UV (UV-A blacklight)
  • Easy rework and repairs — can solder through coat; remove with MG Chemicals' Thinner/Cleaner (cat. no. 435-1L) or Conformal Coating Stripper (cat. no. 8310-100ML)

Applications

  • Printed Circuit boards
  • LED Boards
  • Electric generators, motors and transformers
  • Relays
  • Automotive air bag controllers
  • Cell phones and Computer tablets components
  • Avionics
