M5Stack COM.LTE Module (SIM7600G)

SKU: CE07620 Brand: M5Stack

COM.LTE(4G) is a stackable multifunctional LTE communication module, built-in LTE communication module SIM7600G, supports LTE-TDD/LTE-FDD/WCDMA and GSM frequency bands, supports LTE.CAT4 (downlink speed is 150Mbps), supports voice calls SMS with SMS.

$179.95 AUD, inc GST

$163.59 AUD, exc GST

In stock, ships same business day if ordered before 2PM
Fastest delivery: Tomorrow* Disclaimer:
The shipping address needs to be in the AusPost next day network and eParcel Express is chosen during checkout. On rare occasions, orders may be delayed by up to one business day due to AusPost pickup timings or for order verifications.

Quantity Discounts:

5-10 $157.05 (exc GST)
10+ $152.14 (exc GST)

It has stable performance, small appearance, high cost performance, and can realize the transmission of SMS and data information with low power consumption. The module has a DC power input and can provide 5V-12V power supply through an external power supply.

In order to facilitate the user to configure the pin, the DIP switch is used to set the pin. The onboard microphone and 3.5mm headphone jack support the insertion of headphone with microphone. This module is especially suitable for scenarios that require high-speed network connections, such as video calls, drone data transmission, industrial Internet of Things, etc.

COM.LTE(4G) RXD/TXD can be connected to M5Stack's UART (TX(0/13/17)RX(5/15/16)) by setting the DIP switch, GPIO in M5Stack Fire 16/17 It is connected to PSRAM by default. It is recommended to use any one of the remaining two groups of pins.
Dial the DIP switch on the side of the audio configuration pin to ON when in use

Features

Stackable design
Support voice calls, SMS text messages, cellular data transmission
Independent external power supply
Built-in microphone
AT command control
SIM card type: MicroSIM
Status signal: two LED indicators
External antenna: SMA antenna
Serial communication: UART 115200bps
Frequency band:

LTE-TDD B34/B38/B39/B40/B41
LTE_FDD B1/B2/B3/B4/B5/B7/B8/B12/B13/ B18/B19/B20/B25/B26/B28/B66
WCDMA B1/B2/B4/B5/B6/B8/B19
GSM/GPRS/EDGE 850/900/1800/1900MHz

Data transmission speed:
LTE Cat4

UL:50Mbps
DL:150Mbps

HSPA+

UL:5.76Mbps
DL:42Mbps

WCDMA

UL/DL:384Kbps

EDGE/GPRS

UL/DL:236.8Kbps

Protocol

TCP/IP/IPV4/IPV6/ Multi-PDP/FTP/FTPS/HTTP/ HTTPS/DNS
TLS
RNDIS/ECM
FOTA

Certification

CE/RCM/FCC/IC
PTCRB/GCF
AT&T/Verizon
RoHS/REACH

Includes

1x COM.LTE module
1x SMA antenna

Applications

Remote meter reading system
Automatic Web Spider SMS-notifier
Wireless communication
M2M industrial
Vehicle-mounted
Video

Specification

Frequency band: LTE-FDD/LTE-TDD/WCDMA/GSM
Network protocol: TTCP/IP/IPV4/IPV6/ Multi-PDP/FTP/FTPS/HTTP/ HTTPS/DNS etc.
Communication: UART 115200bps
Net weight: 55g
Gross weight: 90g
Product Size: 54.2*54.2*13.2mm
Package Size: 165*60*37mm
