Jetson Nano Development / Expansion Kit Lite Version, Optional Jetson Nano Core Module

JETSON-NANO-LITE-DEV-KIT

Waveshare Jetson Nano Development Kit

Based on Jetson Nano Module (with 16GB eMMC), it provides almost the same size and thickness as N-VIDIA Jetson Nano 2GB Developer Kit. Compared with the JETSON-NANO-DEV-KIT, the peripheral interfaces are less but the performance of the core module remains the same, which is suitable for the scenarios that require less interfaces, more cost-effective.

comparing the appearance

JETSON-NANO-DEV-KIT

JETSON-NANO-LITE-DEV-KIT
Compatible with Jetson Nano 2GB Developer Kit case

Carrier Board Comparison

Model	JETSON-IO-BASE-A	JETSON-IO-BASE-LITE
USB Port	4 × USB 3.2 Gen 1 Type A 1 × USB 2.0 Micro-B	1 × USB 3.2 Gen 1 Type A 2 × USB 2.0 Type A 1 × USB 2.0 Micro-B
Gigabit Ethernet Port	v	v
HDMI Port	v	v
DP Port	v	-
CSI connector	× 2	× 1
Power Port	DC	USB Type-C
Button	-	Power: PWR BTN Reset: SYS RST

Specification

GPU	128-core Maxwell
CPU	Quad-core ARM A57 @ 1.43 GHz
Memory	4 GB 64-bit LPDDR4 25.6 GB/s
Storage	16GB eMMC + 64GB TF Card
Video Encoder	250 MP/s 1x 4K @ 30 [HEVC] 2x 1080p @ 60 [HEVC] 4x 1080p @ 30 [HEVC]
Video Decoder	500 MP/s 1x 4K @ 60 [HEVC] 2x 4K @ 30 [HEVC] 4x 1080p @ 60 [HEVC] 8x 1080p @ 30 [HEVC]
Camera	1x MIPI CSI-2 D-PHY lanes
Connectivity	Gigabit Ethernet, M.2 Key E expansion connector
Display	HDMI
USB	1 × USB 3.2 Gen 1 Type A, 2 × USB 2.0 Type A, 1 × USB 2.0 Micro-B
Extension Interfaces	GPIO, I2C, I2S, SPI, UART
Dimensions	100 × 80 × 29mm

Compatible with Jetson Nano Module

connect to CSI camera

Supports CSI camera for AI applications such as face recognition, road sign recognition and license plate recognition

4K High Definition output

Support HDMI High-definition Port

3× USB ports

1× USB 3.2 Gen 1 + 2× USB 2.0

USB 3.2 Gen 1 port for high speed data transmission

color-coded 40PIN GPIO header

color-coded header pins with clear labels, handy for use

Introduction

Core module socket
TF card slot
M.2 Key E connector
1.25mm Fan header
PoE pins
PoE module is not included
40PIN GPIO header
2.54mm Fan header
Micro USB port
for USB data transmission
Gigabit Ethernet port
10/100/1000Base-T auto-negotiation, supports PoE if external PoE module is connected

2× USB 2.0 port
1× USB 3.2 Gen 1 port
HDMI port
USB Type-C
for 5V 3A power input
PWR BTN
Power Button
SYS RST
Reset button
MIPI CSI camera connector

Outline dimensions

Ordering options

JETSON-IO-BASE-LITE
The carrier board ONLY, compatible with Jetson Nano Module

JETSON-NANO-LITE-DEV-KIT
The carrier board, along with Jetson Nano module, 64GB TF card, card reader and official heatsink

More available kits

Kit	A	B	C
JETSON-NANO-LITE-DEV-KIT	v	v	v
Necessary accessories (USB cable, cooling fan, ~1.5m Ethernet cable, 5V 3A power supply)	v	v	v
AC8265 dual-mode NIC	v	v	v
IMX219-77 Camera		v	v
7inch HDMI LCD (H)			v

JETSON-NANO-LITE-DEV-KIT-A: wireless NIC kit
With drive-free 5G (867 Mbps) / 2.4 G (300 Mbps) wireless NIC, it supports Bluetooth and WiFi dual modes, and 6DB high-gain dual antennas effectively improve penetration, and make data transmission wider and smoother, which is suitable for mobile networking scenarios.

JETSON-NANO-LITE-DEV-KIT-B: single camera vision kit
If you want to play AI intelligent applications such as face recognition, road sign recognition and license plate recognition, this package is very suitable for you. With an 8 megapixel (3280 x 2464) high-definition camera, it can be used easily in various application scenarios.

JETSON-NANO-LITE-DEV-KIT-C: touch display kit
If the single camera vision package can't meet the requirements, this package with 7-inch IPS touch screen is undoubtedly a better choice. The 1024 x 600 pixel screen can display the images taken by the camera in real time. If you are a beginner, you can also benefit from the graphical operating system, killing two birds with one stone.

Resources & Services

Wiki: www.waveshare.com/wiki/JETSON-NANO-LITE-DEV-KIT

Weight: 0.148 kg

Quick Overview

JETSON-IO-BASE-LITE

JETSON-IO-BASE-LITE (carrier board)

JETSON-NANO-LITE-DEV-KIT

JETSON-NANO-LITE-DEV-KIT (carrier + Nano + heatsink)
64GB TF Card
Card reader

JETSON-NANO-LITE-DEV-KIT-A

JETSON-NANO-LITE-DEV-KIT (carrier + Nano + heatsink)
AC8265 dual-mode NIC
Cooling fan
USB cable (~1.2m)
Ethernet cable (~1.5m)
OPTIONS 5V 3A power adapter
64GB TF Card
Card reader

JETSON-NANO-LITE-DEV-KIT-B

JETSON-NANO-LITE-DEV-KIT (carrier + Nano + heatsink)
AC8265 dual-mode NIC
IMX219-77 Camera
Cooling fan
USB cable (~1.2m)
Ethernet cable (~1.5m)
OPTIONS 5V 3A power adapter
64GB TF Card
Card reader

JETSON-NANO-LITE-DEV-KIT-C

JETSON-NANO-LITE-DEV-KIT (carrier + Nano + heatsink)
IMX219-77 Camera
7inch HDMI LCD (H)
AC8265 dual-mode NIC
HDMI cable
RPi screw pack (4PCS)
USB cable (~1.2m)
Ethernet cable (~1.5m)
Cooling fan
OPTIONS 5V 3A power adapter
64GB TF Card
Card reader
