Gravity: BMM150 Triple Axis Magnetometer Sensor

SKU: SEN0529 Brand: DFRobot
BMM150 is a low-power and low-noise 3-axis digital geomagnetic sensor from Bosch for compass applications. It allows measurements of the magnetic field...
$14.40 AUD, inc GST
$13.09 AUD, exc GST

Available with a lead time
Expect dispatch between Oct 14 and Oct 17

Quantity Discounts:

  • 10-25 $12.70 (exc GST)
  • 25+ $12.44 (exc GST)
- +

0 from local stock, 1 supplier stock; your order will dispatch between Dec 1 to Dec 10. And yes, stock levels and lead times are accurate!

Shipping:

  • $7+ Standard (5+ days*, tracked)
  • $11+ Express (2+ days*, tracked)
  • FREE Pickup (Newcastle only - must order online*)

Shipping costs may increase for heavy products or large orders.

Exact shipping can be calculated on the view cart page.

*Conditions apply, see shipping tab below.

BMM150 is a low-power and low-noise 3-axis geomagnetic sensor from Bosch for compass applications. It allows measurements of the magnetic field and compass angle in three perpendiculars within a measuring range of ±1300uT on X and Y axis and ±2500uT on Z axis.

Featuring small size and lightweight, the sensor has a 2-bit DIP switch for I2C address setup, and 4 addresses are available. Based on Bosch's proprietary FlipCore technology, the performance and features of BMM150 are carefully tuned and thus can offer absolute spatial orientation without calibration, perfectly matching the requirements of all 3-axis mobile applications such as robot navigation & positioning, electric compass, electric map, navigation or augmented reality.

Gravity: BMM150 Triple Axis Magnetometer

Connection Diagram with FireBeetle 2 ESP32-E IoT Microcontroller

Features

  • Programmable interrupt pin
  • Configurable four I2C addresses
  • Low power consumption(170uA)
  • Low noise(0.3-1.4uT)
  • High accuracy(30µT horizontal geomagnetic field component, ±2.5°)
  • Applications

  • Drones
  • Compass
  • Indoor/Outdoor Navigation
  • Head Motion Tracking
  • Augmented Reality
  • Tilt-compensated Electric Map
  • Specification

  • Power Supply: 3.3V-5V
  • Operating Temperature: -40 to 85°C
  • Communication: I2C
  • Resolution: 0.3µT
  • Zero Offset: ±40µT/±2µT (software optimized)
  • Non-linearity: <1%FS
  • Measuring Range: ±1300µT (x & y axis), ±2500µT (z-axis)
  • Supply Current in Active Mode: 170µA(low power mode)/500µA(normal mode)
  • Low Noise: 0.3-1.4µT
  • Accuracy: 30µT horizontal geomagnetic field component, ±2.5°
  • Start-up Time: 3ms
  • Documents

  • Product wiki
  • STP 3D Model
  • 2D CAD Dimensions
  • Schematics
  • Datasheet
  • Parts List

  • Gravity: BMM150 Triple Axis Magnetometer Sensor ×1
  • Gravity-4P I2C/UART Sensor Cable ×1
  • Black Single-row Pin Header-5PIN ×1
  • This product is listed in:

    Sensors>Magnetic
