Conductive Stainless Thread (2Ω)

SKU: FIT0748 Brand: DFRobot

This is a smooth stainless steel fiber conductive sewing thread. One roll has 1m sewing thread, and about 2Ω per 1m. The diameter of the wire is 0.96mm....

$11.70 AUD, inc GST

$10.64 AUD, exc GST

Quantity Discounts:

10-25 $10.21 (exc GST)
25+ $9.89 (exc GST)

Out of Stock

This is a smooth stainless steel fiber conductive sewing thread. It features small resistance, good thermal conductivity, high melting point and high-temperature resistance. One roll has 1m sewing thread, and about 2Ω per 1m. The diameter of the wire is 0.96mm. It can be used for making touchscreen gloves, anti-static clothing, wearable electronic equipment, anti-static brush, driving LED and other small current electronic components.

Note: the thinner the wire, the more resistance it offers.

Conductive Stainless Thread

Conductive Stainless Steel Sewing Thread Selection Guide

Name	Stainless Steel Conductive Sewing Thread(50-60Ω)	Stainless Steel Conductive Sewing Thread(30-40Ω)	Stainless Steel Conductive Sewing Thread(20-25Ω)	Stainless Steel Conductive Sewing Thread(10-15Ω)	Stainless Steel Conductive Sewing Thread(9Ω)	Stainless Steel Conductive Sewing Thread(7Ω)	Stainless Steel Conductive Sewing Thread(2Ω)
Features	1. Small resistance and stable resistivity 2. 650°C high-temperature resistance, 1350°C melting point 3. Safe to wash and reusable	1. Small resistance and stable resistivity 2. 650°C high-temperature resistance, 1350°C melting point 3. Safe to wash and reusable	1. Small resistance and stable resistivity 2. 650°C high-temperature resistance, 1350°C melting point 3. Safe to wash and reusable	1. Small resistance and stable resistivity 2. 650°C high-temperature resistance, 1350°C melting point 3. Safe to wash and reusable	1. Small resistance and stable resistivity 2. 650°C high-temperature resistance, 1350°C melting point 3. Safe to wash and reusable	1. Small resistance and stable resistivity 2. 650°C high-temperature resistance, 1350°C melting point 3. Safe to wash and reusable	1. Small resistance and stable resistivity 2. 650°C high-temperature resistance, 1350°C melting point 3. Safe to wash and reusable
Resistance(O)	50-60Ω	30-40Ω	20-25Ω	10-15Ω	9Ω	7Ω	2Ω
Thread Diameter(mm)	0.18-0.2mm	0.27-0.3mm	0.33mm	0.42mm	0.45mm	0.5mm	0.96mm
Thread Length/Roll	37-45m/Roll	20-27m/Roll	13-18m/Roll	9-11m/Roll	7m/Roll	5m/Roll	1m/Roll
Application	Telefingers gloves, anti-static clothing, wearable electronic devices, anti-static brushes, driving LEDs and other low-current electronic components, etc.
Note	The smaller the resistance value, the thicker the thread, so the length of each roll of these models is different

Features

Low resistance and stable resistivity
High-temperature resistance 650°C, melting point 1350°C
Safe to wash, reusable

Specification

Wire Resistance: 2Ω/m
Length: 1m
Diameter: 0.96mm

Parts List

Conductive Stainless Thread (2Ω) x1

This product is listed in:

Wearables>Thread & Fabric
