The Nano Motor Carrier extends the Arduino Nano 33 IoT into a compact motor-control and sensing platform, combining four motor drivers, encoder inputs and an on-board 9-axis IMU with a single-cell Li-Ion battery charger. It lets you power, measure and control small robots and actuator projects easily.
Use it to drive up to four DC motors, read two quadrature encoders, charge a 1S Li-Ion cell and add actuators or three-pin sensors via the on-board headers; install the Arduino Motor Carrier library to get started quickly.
Technical Specifications
Product | Nano Motor Carrier |
Microcontroller | ATSAMD11 (Arm Cortex-M0+ @ 48 MHz) |
Motor drivers | 4 x MP6522 |
Max input voltage (power terminals) | 4 V (1S Li-Ion battery) |
Max output current per motor driver | 500 mA |
Motor driver output voltage | 12 V |
Over temperature shutdown (DC motor drivers) | Yes |
On-board sensors | 9-axis accelerometer, gyroscope and magnetometer |
Battery charger | On-board charger for single cell Li-Ion batteries (1S) |
Encoder inputs | 2 x quadrature encoder counting ports |
I/O | Series of 3-pin male headers for actuators and sensors |
Notes | Requires external power source to feed motor drivers; connect 1S Li-Ion or external supply to power motors |
