Aluminum M.2 2280 Solid-state Drive Heat Sink (Compatible with LattePanda Sigma)

SKU: FIT0969 Brand: DFRobot
The Aluminum alloy SSD cooling vest is compatible with M.2 2280 solid-state drive. Features superior heat dissipation and advanced genetic heating pads...
Special Price $17.23 AUD, inc GST
Regular Price $21.99 AUD, inc GST
$15.66 AUD, exc GST
Special pricing ends 28 July 2024
* this special may end earlier than shown

Available with a lead time
Expect dispatch between May 10 and May 13

- +

0 from local stock, 1 supplier stock; your order will dispatch between Dec 1 to Dec 10. And yes, stock levels and lead times are accurate!

Shipping:

  • $6+ Standard (5+ days*, tracked)
  • $10+ Express (2+ days*, tracked)
  • FREE Pickup (Newcastle only - must order online*)

Shipping costs may increase for heavy products or large orders.

Exact shipping can be calculated on the view cart page.

*Conditions apply, see shipping tab below.

This is an all-aluminum M.2 solid-state drive radiator. The aluminum alloy slot design greatly increases the heat dissipation area, which can cool the M.2 solid-state drive to a safe temperature and avoid overheating. Depending on the environment, the cooling effect can reach 10°C to 30°C.

The Structure of M.2 2280 SSD Heat sink

The radiator is equipped with a silicone gasket with a heat dissipation performance of up to 14.8w/m.k. It adopts a full electroplating reflow soldering process.The pure aluminum electroplated passive fin group and pure aluminum electroplatedbase provide excellent heat dissipation performance.The heat dissipation area reaches 4500mm² and uses a single tube and double joints. Welding machine technology provides the ultimate cooling experience.

M.2 2280 SSD Heat sink with 4 height-adjustable screws

The radiator adopts a double-sided clamp design and is equipped with 4 height-adjustable screws, which is suitable for M.2 SSD of various heights, ensuring stable installation and better protecting M.2 SSD.

Overview of M.2 2280 SSD Heat sink

The radiator also uses advanced heat-conducting pads, made of nano silicone grease material, which has good thermal conductivity. The gasket is soft and malleable enough to be compatible with the uneven slopes of the M.2 SSD surface, and the low-viscosity design will not damage the SSD warranty label.

Features

  • Aluminum alloy
  • With thermal conductive silicone sheet
  • Compatible with 2280 SSD
  • Thermal conductive heat pipe + passive fin structure, strong heat dissipation ability
  • Specification

  • Size: L79 * W24 * H43.5mm
  • Weight: 80g
  • Fin Specifications: thickness = 0.4mm, spacing = 1.8mm
  • Number of fins: 32pcs
  • Catheter diameter: 6mm
  • Parts List

  • M.2 2280 SSD Heat sink x1
