USB 3.0 Capture Card

SKU: WS-24211 Brand: Waveshare

USB Port High Definition HDMI Video Capture Card, For Gaming / Streaming / Cameras, HDMI To USB...

$29.05 AUD, inc GST

$26.41 AUD, exc GST

In stock, ships same business day if ordered before 2PM
Delivered by Tue, 14th of May

Quantity Discounts:

10-25 $25.62 (exc GST)
25+ $25.09 (exc GST)

This adapter is a video capture card that enables users to connect their HDMI-enabled devices such as gaming consoles, cameras, and streaming devices to their computer via a USB port. The video capture card supports high definition video quality and captures video signals in real-time, allowing users to record or stream video content directly to their computer.

The HDMI to USB converter is easy and flexible to use with no need for any external power supply or drivers to be installed. It is a plug-and-play device that can be used with a variety of operating systems and software platforms.

This adapter is ideal for gamers, content creators, YouTubers, and live streamers who want to capture their gameplay or any other video content in high definition and share it with their audience in real-time. The HDMI to USB converter card also offers a cost-effective and easy way for businesses to record or stream presentations, conferences, training sessions, and other events.

This adaptor would work great as part of a Hyperbian Ambient Screen lighting build, read our guide here.

Specifications

Product	HDMI to USB3.0 Adapter
Input	HDMI
	Input resolution up to 4K (3840*2160@30Hz)
	HDMI 1.4B compliant
Output	USB3.0
	Output resolution up to 1080P(1920*1080@60Hz)
	Supports YUV422 and MJPEG modes
	UVC1.0 and UAC1.0 protocol compliant
Transmission Latency*	As low as 50ms
Audio	Default 48KHz stereo output
System support	Windows, Linux, macOS, Android
Software support	OBS, Potplayer, QuickTime, XSplit, etc.

* test data are from Waveshare laboratory, and the actual performance may be different according to the device you are using.Wide variety of hosts support

Dimensions

Resources

Wiki for USB 3.0 Capture Card
