Edge Carrier

Prototype with the Unexpected Maker Edge M.2 development boards!

$27.23 AUD, inc GST

$24.75 AUD, exc GST

In stock, ships same business day if ordered before 2PM
Delivered by Tue, 18th of Nov

Turn your EdgeS3[D](and future UM Edge boards) into a plug-and-play development platform. This Edge Carrier board gives you USB-C convenience, robust M.2 B-Key retention, and full 2.54 mm access to your module’s I/O for fast bring-up and iterative prototyping.

Technical Specifications

Host interface

USB-C for power and data

Module connector

M.2 B-Key connector with patch nut and M.2 screw

I/O breakout

2.54 mm headers exposing all EdgeS3[D] pads

User controls

Reset and Boot (IO0) buttons

Power visibility

3V3 input power LED

Aux power

1.25 mm battery connector

Prototyping power

3V3 header pin for external peripherals and to verify the EdgeS3[D] regulator is powered

Compatibility

EdgeS3[D]

Future Edge products

Resources

Unexpected Maker EdgeS3D Carrier reference design on GitHub: design files and KiCad project

What’s Included

Pre-assembled Edge Carrier PCB
2 sets of 20-pin 2.54 mm male headers
2 sets of 20-pin 2.54 mm female headers
1 x 4-pin 2.54 mm male header
1 x M2x4 mm mounting screw to secure your EdgeS3[D]

Note: EdgeS3[D] module is not included.
