M5Stack Mini CAN Bus Module 5-24V

SKU: CE010053 Brand: M5Stack

Explore the M5Stack Mini CAN Bus Module, a compact communication module featuring high-speed data transfer up to 5Mbit/s, CAN FD protocol support, and wide voltage input range of 5-24V for automotive and industrial applications.

$16.55 AUD, inc GST

$15.05 AUD, exc GST

Available with a lead time
Expect dispatch between Dec 02 and Dec 13

Quantity Discounts:

10-25 $14.59 (exc GST)
25+ $14.29 (exc GST)

The M5Stack Mini CAN Bus Module is a compact yet powerful communication solution designed for high-speed data transfer in automotive and industrial applications. Built around the reliable TJA1051T chip, this module delivers exceptional performance with data rates up to 5Mbit/s while supporting the advanced CAN FD (Flexible Data Rate) protocol.

Key Features

High-speed data transmission up to 5Mbit/s with CAN FD support
Wide voltage input range of 5-24V through integrated DCDC power supply
Built-in electromagnetic compatibility (EMC) and electrostatic discharge (ESD) protection
Compliant with ISO 11898-2:2016 and SAE J2284-1 to SAE J2284-5 standards
Compact form factor: 32mm x 24mm x 10.2mm

Technical Specifications

Protocol Standards: ISO 11898-2:2016, SAE J2284-1 to SAE J2284-5
Operating Voltage: 5-24V DC
Communication Speed: Up to 5Mbit/s in CAN FD mode
Protection: EMC and ESD protection mechanisms
Dimensions: 32mm x 24mm x 10.2mm
Weight: 7.8g

How to Use

Implementation of the Mini CAN Bus Module is straightforward using the provided Grove interface. For expanded connectivity options, consider pairing with the M5Stack Unbuckled Grove Cable (200mm) for flexible positioning. The module can be integrated into existing systems using the following steps:

Connect the module to your microcontroller using the Grove cable
Supply power within the 5-24V range
Configure your microcontroller's CAN communication parameters
Begin data transmission using the CAN protocol

What's in the Box

1x Mini CAN Unit
1x Grove Cable (20cm)

Compatibility

The Mini CAN Bus Module integrates seamlessly with various M5Stack development boards, including the M5Stack Core2 ESP32 IoT Development Kit and M5Stack ESP32 Basic Core IoT Development Kit. For expanded functionality, it can be paired with the M5Stack COMMU Module to create comprehensive communication solutions.

Additional Resources

Technical Documentation

About M5Stack

M5Stack specialises in developing modular electronic solutions for prototyping and education. Their products are designed to be stackable, programmable, and easily integrated into various applications, making them ideal for rapid development and learning environments. The company's commitment to open-source hardware and software has established them as a leading provider of development tools and IoT solutions.
