M1W Dock AI Development Kit

SKU: KIT0145 Brand: DFRobot

Artificial intelligence tide is sweeping across our world. All open sources developers and AI geekers, good news, come to see this excellent M1W Dock AI development...

$74.70 AUD, inc GST

$67.91 AUD, exc GST

Available with a lead time
Expect dispatch between May 27 and Jun 03

Quantity Discounts:

6+ $66.89 (exc GST)

Note: Lead time of this product is unknown, sorry for the inconvenience.

Artificial intelligence tide is sweeping across our world. All open sources developers and AI geekers, good news, come to see this excellent M1W Dock AI development kit! With integrated Micropython in this module, you can start your AI development with ease!
The development kit adopts professional AI chip K210, a dual-core RISC-V with an FPU. It serves as the core unit and dual-core processing with independent FPU, 64-bit CPU and 8M in-built SRAM. With a 400Mhz adjustable nominal frequency, it supports multiplication, division and square root operation. In the AI processing, AI chip K210 can perform operations such as convolution, batch normalization, activation and pooling. At the same time, the pre-processing of voice direction scanning and voice data output can also be performed. This module can realize face detection, voice, color and object recognition, MNIST handwritten digit recognition, feature map visualization, tiny yolov2 and so on.
M1W Dock Embedded AI development board integrates M1W Dock, GC0328 camera, 2.4 inches LCD with 320*240 resolution, and it also has built-in microphone, TF card slot and on-board USB to serial chip for downloading and debugging codes. With so many powerful functions, I am sure this product would be the best choice for all AI enthusiasts!

Features

Digital Video Port (DVP) interface support
Universal Asynchronous Receiver/Transmitter(UART)
Direct Memory Access Controller (DMAC)
I2C, I2S, SPI interfaces
Joint Test Action Group(JTAG)
Field Programmable IO Array (FPIOA/IOMUX)
Neural Network Processor (KPU)
Audio processor (APU)
Fast Fourier Transform (FFT) hardware accelerator
AES and SHA256 algorithm hardware accelerators

Specification

Machine Vision
Machine Hearing
Low power, better vision processing speed and accuracy
KPU high performance Convolutional Neural Network (CNN) hardware accelerator
Firmware encryption support
Unique programmable IO array maximises design flexibility
FPC24P socket for DVP camera and 8-bit MCU LCD
3.3V/1.8V dual voltage IO support eliminates need for level shifters
Access to all 72-pin full pin lead-out, freely mappable
USB Type-C interface
Power amplifier IC for use with speakers
Built-in microphone
TF card slot
On-board Wifi, adopt ESP8285 chip
Onboard high-speed DAC
Microphone Array expansion board for sound localization, beam forming, speech recognition, etc.

Documents

Product wiki

Product Data

MaixDock Datasheet

Parts List

M1W Dock AI Development Kit x1
