Gravity: MAX30102 PPG Heart Rate and Oximeter Sensor (I2C/UART)

SKU: SEN0518 Brand: DFRobot
DFRobot Gravity: MAX30102 heart rate and blood oxygen sensor module integrates the Maxim MAX30102 chip and an MCU heart rate and blood oxygen algorithm...
$35.90 AUD, inc GST
$32.64 AUD, exc GST

In stock, ships same business day if ordered before 2PM
Delivered by Mon, 2nd of Dec

Quantity Discounts:

  • 10-25 $31.65 (exc GST)
  • 25+ $31.00 (exc GST)
- +

1 from local stock, 1 supplier stock; your order will dispatch between Dec 1 to Dec 10. And yes, stock levels and lead times are accurate!

Shipping:

  • $7+ Standard (5+ days*, tracked)
  • $11+ Express (2+ days*, tracked)
  • FREE Pickup (Newcastle only - must order online*)

Shipping costs may increase for heavy products or large orders.

Exact shipping can be calculated on the view cart page.

*Conditions apply, see shipping tab below.

DFRobot Gravity: MAX30102 heart rate and blood oxygen sensor module integrates the Maxim MAX30102 chip and an MCU with heart rate and blood oxygen algorithm.

The MAX30102 uses PPG(PhotoPlethysmoGraphy) to measure data, which will be converted into heart rate and oximetry values when processed by the MCU, then output through I2C or UART, making the sensor easy to useand greatly reducing resource occupation of the main controller. Meanwhile, the corresponding upper computer is provided to allow you to conveniently read data by a PC.

Note:

  • The pressure may change when the finger is directly pressed down the sensor, which will affect the data output. So please try to fix the sensor on your finger.
  • Wear the sensor on your finger and there is no difference in the direction of wearing.
  • This product is not a professional medical instrument and should not be used as an auxiliary accessory in diagnosis and treatment
  • Gravity: MAX30102 Heart Rate and Oximeter Sensor

    Wear Instructions

    Gravity: MAX30102 Heart Rate and Oximeter Sensor

    Connect with DFRduino UNO R3

    Gravity: MAX30102 Heart Rate and Oximeter Sensor

    Connect with Raspberry Pi

    Features

  • Microcontroller with algorithm integrated
  • Data can be read directly through the host computer
  • Applications

  • Heart rate blood oxygen project
  • Home heart rate oximeter
  • Long-term heart rate and blood oxygen monitoring project
  • Specification

  • Power Supply Voltage: 3.3V/5V
  • Working Current: <15mA
  • Communication Method: I2C/UART
  • I2C Address: 0x57
  • Serial Port Baud Rate: 9600
  • Operating Temperature Range: -40?~85?
  • Product Size: 25.5×32mm/0.98×1.26inch
  • Documents

  • Product wiki
  • Schematics
  • Dimension
  • MAX30102 Datasheet
  • Parts List

  • Gravity: MAX30102 Heart Rate and Oximeter Sensor x1
  • Gravity-4P I2C/UART Sensor Connector x1
  • Strap x1
  • This product is listed in:

    Sensors>Biometric
