Edge-Launch SMA Connector for 1.6mm / 0.062 Thick PCBs

SKU: ADA1865

$4.50 AUD, inc GST
$4.09 AUD, exc GST

More Views

Edge-Launch SMA Connector for 1.6mm / 0.062 Thick PCBs
4.5 AUD

SKU: ADA1865

$4.50 AUD, inc GST
$4.09 AUD, exc GST
0 units ship today
Contact us if you need this product urgently

This is a great connector for anyone doing RF work, when an SMA connector is required. It hugs the edge of a standard 0.063" thick PCB and 'launches' off of the edge. Adafruit like these for their ease of soldering and low profile. Mates with any SMA plug, They also have an SMA to RP-SMA in case your antenna is RP-SMA

You can find an Eagle footprint for this part in the Adafruit Eagle Library, it's called SMA_EDGELAUNCH

Technical Details

  • Impedance: 50 ohm
  • Diameter of Jack: 6.1mm / .24"
  • Width of Plug: 6.4mm / .25"
  • Total Length of Connector: 13.5mm / 0.53"
  • Weight: 2g
