- True 5 1/2. digits resolution
- 123 rdgs/s Maximum Reading Speed
- 0.015% accuracy of DC Voltage
- Command compatibility: Replace mainstream DMM randomly via the compatibility of their command
- Patented Any Sensor test capability
- 256x64 pixels LCD display, to support multi-display and screen menu
- Connectivity: USB Device
- V DC 200mV - 1000V 0.015% Rdg + 0.003% Range
- V AC RMS 200mV - 750V, 0.20% Rdg + 0.05% Range
- A DC 200uA - 10A 0.055% Rdg + 0.005% Range
- A AC 20mA - 10A 0.30% Rdg + 0.10% Range
- Resistance 2 Wire & 4 Wire 200ohm - 100Mohm
- Capacitance 2nF - 10000µF
- Diode 2.4V
- Continuity 2kohm
- Frequency & Period 200mV - 750V
- Maths Functions "Pass/Fail" Limit Test, Standard Deviation, Histogram, Relatively, Null, MaxlMin/Avg, dBm, dB
- Other Functions Built-in 10 groups of configuration storage,10 groups of configuration storage of any sensor, 2048 historical reading data record and check, 10 groups of historical datum storage, Exterior trigger input and VMC output, Reading hold. Single trigger
- Display Multi-display, Menu, Multi-language help and Waveform display
- Safety CAT I 1000V/CAT II 600V
