Wireless ISP function provides the wireless Internet access in areas with on wired ISP infrastructure. Easily setup a WPA encrypted secure connection at a push of the WPS button. WAN Port supports up to 30 meters (100 feet) Passive Power over Ethernet. WDS wireless bridge provides seamless bridging to expand your wireless network.
Features
- 150Mbps wireless data transfer ideal for lag-free video streaming, online gaming and Internet calling
- Client Router Mode supports WISP Internet connection, allowing users to share an Internet connection wirelessly or via cables
- WAN Port supports up to 30 meters (100 feet) Passive Power over Ethernet
- Easily setup a WPA encrypted secure connection at a push of the WPS button
- WDS wireless bridge provides seamless bridging to expand the wireless network
- IP QoS ensures smooth video streaming or lag-free online gaming experience
- Built-in NAT and DHCP servers support static IP address distribution
- Supports PPPOE, Dynamic IP, Static IP, L2TP, PPTP, BigPond Cable Internet access
- Supports Virtual Server, DMZ, UPnP, DDNS, Static Routing, VPN Pass-through
- Supports WEP, WPA/WPA2, WPA-PSK/WPA2-PSK (TKIP/AES) authentication
- Supports configuration backup/restore and firmware upgrades
- Fully compatible with all IEEE 802.11 b/g/n products
- Detachable antenna allows for stronger antenna upgrades (RP-SMA connector)
- Built-in Quick Setup Wizard for easy network settings and security configurations
Specifications
- WAN Type: Dynamic IP/Static IP/PPPoE/PPTP/L2TP/BigPond
- DHCP: Server, Client, DHCP Client List, Address Reservation
- Quality of Service: WMM, Bandwidth Control
- Port Forwarding: Virtual Server,Port Triggering, UPnP, DMZ
- Dynamic DNS: DynDns, Comexe, NO-IP
- VPN Pass-Through: PPTP, L2TP, IPSec (ESP Head)
- Access Control: Parental Control, Local Management Control, Host List, Access Schedule, Rule Management
- Firewall Security: DoS, SPI Firewall, IP Address Filter/MAC Address Filter/Domain Filter, IP and MAC Address Binding
- Management: Access Control
- Local Management
- Remote ManagementInterface: 4 10/100Mbps LAN Ports, 1 10/100Mbps WAN Port
- Button: WPS Button, Reset Button, Power On/Off Button
- External Power Supply: 9VDC / 0.6A
- Wireless Standards: IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
- Antenna: 5dBi Detachable Omni Directional (RP-SMA)
- Dimensions: 174W x 118D x 33H mm
