ModMyPi BattBorg - Pi Battery Power Board (Soldered Kit)

SKU: CE05820 Brand: ModMyPi

Retired Product

Search for an alternative

This product has been retired. It is no longer available, but this page has been kept for reference.

The BattBorg is a plug and play power converter for your Raspberry Pi which allows you to power the Raspberry Pi with batteries! It's great for robot projects, or where you need to leave your Pi unmanned for extended periods without a wired power source (outside sensor projects etc.)

The BattBorg uses a highly efficient (~90%) OKI78SR DCDC converter which has a maximum 1.5A output and, due to it's efficiency, requires no heatsink. It will work with most batteries/battery packs that are between 7-36V so it's great for 12V car batteries, 8xAA battery packs, and so on.

BattBorg comes in several different kits. This purchase is for the Full Unsoldered Kit, which includes an unassembled BattBorg, one 8 x AA battery holder, and the cables to hook it all up. The BattBorg in this kit requires soldering (but you can do so in your own configuration!), then all you need is a Raspberry Pi, and batteries, and you're ready to roll!

Features

5V 1.5A Max Output
~90% Efficient
Compatible with battery packs (or batteries) between 7V - 36V
Plugs into GPIO Pins 2, 4 & 6
Up to 14 Hours Run-Time @ 15% Load (8 x AA Batteries)
Compatible with Model A, B, A+, B+, 2, 3, Zero, Zero W

Contains

Assembled & Soldered BattBorg PCB
8 x AA Battery Pack
3 Pin Cable M/F Cable
PP3 Connector Cable
Mounting Pillar & Screw
