MG Chemicals 422B Silicone Modified Conformal Coating 1L

422B is a one-part, acrylic-silicone blend conformal coating that cures to a durable, flexible and smooth finish. It is easy to apply and can be handled in only 8 minutes. It may be removed with appropriate strippers, or soldered through for repair or rework.

422B is designed for applications where both high service temperature and flexibility are required. It puts minimum stress on components during thermal cycling, making it ideal for applications that involve a wide temperature range. It provides strong protection against moisture, corrosion, fungus, dirt, dust, thermal shock, short circuits, high-voltage arcing, and static discharge.

Features

• Certified UL 94V-0 (File# E203094)
• Maximum constant service temperature of 200 °C [392 °F]
• Fluoresces under UV-A light
• Validated for selective robotic coating equipment including PVA and Nordson ASYMTEK
• Excellent corrosion resistance—tested in salt spray environment with no oxidation or coating damage

Specifications

• Catalog Number: 422B-1L

• Net Volume: 945ml (1.99pt)
• Net Weight: 869g (1.91lb)
• Packaging: Can

Datasheet
