u.FL connectors are very small surface-mount parts used when an external RF antena is desired but a big bulky SMA connector takes up too much space. Adafruit use this part...

Here is a tiny 4-pin Qwiic 1mm JST connector. This connector is used on all of our Qwiic-based boards and can be used to create your own I2C-based device compatible...

USB Type ‘A’ Female SMD connector. For use with any PCB that will be used with a Type A to Type A USB cable. Designed to mount to the UBW32.

USB-C is quickly becoming more and more prominent in the maker community because, let’s be honest, who likes trying three times to insert USB into a port? This is...

This is a 3.5mm TRRS SMD audio jack. TRRS connectors are the audio-style connectors that you see on some phones, MP3 players and development boards. TRRS stands for “tip, ring, ring, sleeve,” which reflects the fact that, unlike a standard stereo connector, this actually has three conductors and a ground. Some devices use the extra conductor for a microphone (like hands-free headsets) or to carry a video signal (like in some MP3/MP4 players).

Here is a six pin vertical 1.0mm pitch connector. It is useful if you need something very tiny as a connection. These are not the standard JST type connectors we use on most of our boards, but are actually the much smaller JST-SH type.

USB Type ‘Mini-B’ Female SMD connector. This is a 5-pin Mini-B surface mount connector commonly found in MP3 players, media/disk readers, USB hubs, pretty much anything small and USB.

If you're a DIY enthusiast who'd like to update your power only project's connection to the latest USB standard, here is a 10-pack of USB C power only jack connectors! They're sturdy metal with 4 through-hole mounting tabs. It's really hard to rip these off a PCB. In an SMT line, you can just paste over the through-hole slots, and the pads will solder in place.

This 1.27mm pitch, 2x5 male SMT Box Header is the same one used on Adafruit's SWD Cable Breakout Board. The header alone is great if you want to incorporate this piece...

This is a 40-pin surface mount FPC (Flat Printed Circuit) connector...

This is a SMD 4-pin right angle male header. We use this header on our Graphic LCD Serial Backpack.

Adafruit have carrying a new 1.27mm pitch 2x5 Mini SWD 0.05" Pitch Connector. It's a tinier, bite-sized version of the Box Header used on Adafruit's SWD Cable Breakout Board. Instead...

This 50-pin FPC SMT top-contact connector fits perfectly with Adafruit's 2.8" TFT display with resistive touch screen. It is fine pitch so it is not so easy to solder!...

These are the surface mount 50 pin 0.5mm Board to Board Double Slot Male Connectors found on the Alchitry FPGA boards. These headers allow for Alchitry FPGA Boards...

Here is a six pin horizontal 1.0mm pitch connector. It is useful if you need something very tiny as a connection. These are not the standard JST type connectors we use on most of our boards, but are actually the much smaller JST-SH type. Check the drawing below.

This is a two pin, compact surface mount JST connector...

If you're a DIY enthusiast who'd like to update your project's connection to the latest USB standard, here is a 10-pack of USB C plug connectors! They can be pick-and-placed onto your design, and then plugged directly into a USB C port.

These are the surface mount 50 pin 0.5mm Board to Board Double Slot Female Connectors found on the Alchitry FPGA boards. These headers allow for Alchitry FPGA Boards...

The micro:bit Edge Connector allows you to expand the capabilities of the micro:bit development platform. This version of the connector features 40, right angle...

This is a 16-pin surface mount dual contact 0.5mm pitch ZIF FPC connector...

Here is a tiny 4-pin Qwiic 1mm JST connector. This connector mounts to allow you to connect your cable vertically, great for tight spaces. This connector is used...

If you're a DIY enthusiast who'd like to update your project's connection to the latest USB standard, here is a 10-pack of USB C jack connectors! They're sturdy...

This is a common SMD barrel-type power jack for DC wall supplies. These are compatible with our DC wall supplies and have a 5mm jack, with a 2.1mm center pole diameter.

A simple 2-pin connector that is compatible with the "JST PH 2-pin" connector - perfect for soldering to the bottom of Adafruit's 3.3V Logic Trinket and 5V Logic Trinket!...

If you want to do more with the BBC micro:bit, getting those pins from the card-edge connector is going to be your first hurdle. Unlike many dev-boards, the micro:bit isn't breadboard-friendly. That makes the 'bit durable and easy to manufacture but means you need a special connector.

This is a SMD 6 pin right angle male header. We use this header on our LilyPad Main Board.

Amphenol FCI FFC/FPC Flexible Circuit Connectors are a broad range of innovative connector solutions to terminate FFC/FPC. This 24-Pin FPC connector has a 0.5mm...

Add tons of storage to your next project with this micro SD card socket. Adafruit use this part in all Adafruit's designs and it works great with any microSD ('transflash') of...

These two SMT Socket Headers alone are, well, lonely. But pair them with any of our Feather boards and you're in business!
