Capacitive Proximity and Touch Button Control Module - IQS127D

SKU: 017-MB-SM22112

$13.99 AUD, inc GST
$12.71 AUD, exc GST

More Views

Capacitive Proximity and Touch Button Control Module - IQS127D

SKU: 017-MB-SM22112

$13.99 AUD, inc GST
$12.71 AUD, exc GST


  • $6.95 Standard (2-4 days, tracked)
  • $9.95 Express (Overnight*, tracked)
  • $3 Economy Post* (3-7 days, no tracking)
  • FREE Pickup (Newcastle only)

Shipping costs may increase for heavy products or large orders.

Exact shipping can be calculated on the view cart page.

*Conditions apply, see shipping tab below.

This product has been retired and kept here for reference.

This is an awesome minimized capacitive sensor module which you can use in many applications where touch sensing or proximity sensing is required, such as lighting controls, touch pads, etc. This module integrates IQS127D, a fully integrated capacitive sensor having dual outputs- Physical Contact (Touch) and Proximity output. Two green LEDs are soldered on this board as the indicators of the output pins. This module can be powered by DC3.0V to 5.0V.


  • Size: 30.70(L) × 23.00(W) × 2.80(H) ±0.2mm
  • Minimum component solution
  • Default configuration – active low
  • Low Power Consumption
  • 6-pin header is provided for easy connection
  • Two mounting holes ensures easy fixing


  • Supply voltage: DC3.0V to 5.0V
  • Operating current: 10mA (all LEDs on)
  • Normal Power Response time
    Proximity: 39.28ms to 113.40ms
    Touch: 9.82ms to 37.80ms
  • Operating temperature: -20°C to 60°C


  • Office equipment, toys, sanitary ware
  • Flame proof, hazardous environment Human Interface Devices
  • Proximity detection enables backlighting activation
  • Wake-up from standby applications
  • Replacement for electromechanical switches
  • Find-In-The-Dark (FITD) applications
  • Automotive: Door pocket lighting, electric window control

Package Contents:

  • Capacitive Proximity and Touch Button Control Module - IQS127D ×2
  • 6-pin Header ×2
