Arduino Opta Ext A0602

SKU: AFX00007 Brand: Arduino

Arduino Pro Opta Ext A0602 enhances your Arduino Opta’s real-time control, monitoring and predictive maintenance applications with the addition of 6...

$449.95 AUD, inc GST

$409.05 AUD, exc GST

Available with a lead time
Expect dispatch between Jun 20 and Jun 24

Quantity Discounts:

5+ $392.68 (exc GST)
15+ $384.50 (exc GST)

Arduino Pro Opta Ext A0602 enhances your Arduino Opta’s real-time control, monitoring and predictive maintenance applications with the addition of 6 programmable inputs, 2 programmable outputs and 4 PWM outputs.
Just snap on the module to extend your system’s capabilities flexibly and quickly, and manage the new I/Os from the Opta base unit seamlessly, taking advantage of the open and widely known Arduino ecosystem or PLC IDE IEC 61131-3 programming environment.

Key benefits include:

Flexible inputs: 4 analog inputs, user-programmable for 0-10 V, 0/4-20 mA, or temperature measurement via RTD PT100 2 wires and 2 analog inputs, user-programmable for 0-10 V, 0/4-20 mA, or temperature measurement via RTD 3-wire PT100 sensors.
Configurable outputs: 2 analog outputs (0-10 V or 0/4-20 mA).
4 digital PWM outputs.
Up to 5 snap-on modules can be managed to multiply and mix a set of I/Os with seamless detection: snap them right next to your Opta base module and use the I/Os as native Opta resources.
Extend your hardware capabilities while keeping programming accessible, by using the Arduino IDE with its wide range of ready-to-use sketches, tutorials and libraries.
Put your new I/Os easily to work with the PLC IDE for IEC 61131-3 PLC languages, taking advantage of its low-code approach and pre-mapped resources.
Extend the Opta’s benefits of real-time remote monitoring via intuitive Arduino Cloud dashboards and secure communication to a wider set of connected devices.
Reliable by design, thanks to industrial certifications and Finder’s expertise in electronic devices.
Easy DIN rail installation.

Applications

Increase with great efficiency the variety of analog data managed by any physical solution, from sensors to actuators, both with 0-10 V and 0/4-20 mA signals. The data, collected in real time and with great accuracy, allows you to monitor and control industrial applications automatically, with Opta’s impeccable precision.
