52Pi Low-Profile ICE Tower Cooler for Raspberry Pi 4 / 3B+ / 3B
Desktop-PC-style tower cooling, shrunk down for the Pi 4 – with a colour-cycling fan to top it off.
Out of Stock
Sign up to get notified when it's available to order.
A miniature tower heatsink and fan that bolts straight onto your Raspberry Pi's processor, borrowing the single-stack cooler design from desktop gaming PCs.
The Raspberry Pi 4 runs hot under sustained load, and once the SoC reaches its thermal limit it throttles to protect itself. A copper heat pipe draws heat from the CPU up into a stack of aluminium fins, where a 40 mm fan pushes it away. That makes this a good fit for media centres, home servers and overclocking projects that keep the CPU busy for long periods.
The low-profile design keeps the tower compact, and the fan runs from the Pi's own GPIO header, so you don't need a separate power supply. Steel mounting brackets, brass standoffs and thermal pads are included for the Pi 4 Model B, 3 Model B+ and 3 Model B.
Setup takes a few minutes:
- Fit the mounting brackets to the cooler
- Apply a thermal pad to the Pi's SoC
- Secure the brackets to the Pi with the standoffs and nuts
- Connect the red lead to a 5V pin and the black lead to GND
Features
- Draws heat away from the CPU quickly, thanks to a 5 mm copper heat pipe feeding a single-stack fin tower
- Low-profile tower that keeps the build compact without giving up much fin area
- Powered from the GPIO header (5V, 0.4 W), so no extra supply or cabling is needed
- Runs quieter if needed: move the red lead from 5V to 3V3 for lower fan speed and noise (the LEDs dim too)
- Colour-changing LED fan that cycles automatically, with no setup needed
- Acrylic protection panel and steel brackets for a sturdy, protected install
- Includes all the hardware, thermal pads and a screwdriver for Pi 4B, 3B+ and 3B
Specifications
| Property | Specification |
|---|---|
| Compatibility | Raspberry Pi 4 Model B, 3 Model B+, 3 Model B |
| Cooler type | Low-profile single-stack tower heatsink |
| Heat pipe | 5 mm copper |
| Fan | 40 mm, colour-changing LED |
| Supply voltage | 5V DC (from GPIO header) |
| Rated power | 0.4 W (5V, 0.08 A) |
| Connection | GPIO jumper leads: red (5V), black (GND) |
| Mounting | Steel brackets, M2.5 standoffs and nuts |
| Dimensions (approx.) | 62 x 43 x 40 mm |
Resources
What's Included
- 1x Low-profile ICE Tower cooler with RGB fan
- 1x Mounting bracket pack (for Pi 4B / 3B+ / 3B)
- 1x Acrylic protection panel
- 4x M2.5 x 6+6 mm brass standoffs
- 4x M2.5 nuts
- 6x M2.5 x 6 mm screws
- 3x Thermal pads
- 1x Screwdriver
- 1x Instruction sheet
