Solarbotics RW2 Wheel (external set screw)

SKU: POLOLU-642 Brand: Pololu

Retired Product

Search for an alternative
This product has been retired. It is no longer available, but this page has been kept for reference.

Solarbotics RW2 rubber wheel with black aluminum hub.

The Solarbotics RW2 rubber wheel has a black, anodized aluminum hub with a generously thick silicone rubber tire for maximum traction (great for minisumo robots or fast line-following robots that need traction when rounding corners).

The rubber tire has a diameter of 1.1 inches (28 mm) and a width of 0.67 inches (17 mm), and it has a 20D durometer. The aluminum hub is drilled for an 3 mm axle. Secure the wheel to your motor shaft with the included 4-40 hex set screw (requires a 0.050-inch hex wrench). The wheel assembly weighs 12 grams. If you are looking to shave some width off your robot design, consider the Solarbotics RW2i wheel, which is a similar design with but has an internal set screw.

This high-traction wheel works with Pololu's 3 mm shaft gearmotors such as Pololu's micro metal gearmotors and the GM12a, GM13a, GM14a, and GM18mini metal gearmotors.

Included Parts

  • One hub
  • One tire
  • One set screw

A 0.05" hex wrench (not included) is required for mounting the wheel. The wheels are sold individually, NOT in pairs.

People often buy this product together with:

Pololu Ball Caster with 3/8 Pololu Ball Caster with 3/8" Plastic Ball
Pololu Ball Caster with 3/8 Pololu Ball Caster with 3/8" Metal Ball
Pololu Micro Metal Gearmotor Bracket Pair - Black Pololu Micro Metal Gearmotor Bracket Pair - Black

Dimensions

Size: 1.1" diameter; 0.5" wide
Weight: 12 g
