Tri-Color USB Controlled Hemisphere Alarm Light with Buzzer

SKU: ADA5126 Brand: Adafruit

With this USB Controlled Round Lamp with Buzzer, you can easily monitor and alert humanoids as to the status of a project, machine, or even if...

$204.95 AUD, inc GST

$186.32 AUD, exc GST

Available with a lead time
Expect dispatch between May 17 and May 20

Quantity Discounts:

5-10 $178.86 (exc GST)
10+ $173.27 (exc GST)

With this USB Controlled Round Lamp with Buzzer, you can easily monitor and alert humanoids as to the status of a project, machine, or even if the bathroom is occupied!

Unlike Adafruit's "12V" style tower lights, no wiring or microcontroller programming is required. It's completely plug-and-play for use with any computer that has a USB port, even a Raspberry Pi SBC - so they recommend it when you just want to get something running and don't want to noodle around with 12V power plugs and transistors.

The buzzer light is powered and controlled over USB, so just plug it right in. Inside is a microcontroller connected over a CH43x USB-to-UART chip, so you'll need to install a CH43x driver for the COM/Serial port to show up.

Once the serial port is created, connect to it over 9600 baud and send command codes to turn on and off the LEDs and enable/disable the buzzer. There's also a blink command, so you don't have to continuously turn on/off the LED to have a pulsing/blinking effect. See below for an example Python script that will toggle everything on/off to test.

Technical Details

Python code example to control the lamp over USB:

"""Example for Adafruit USB tower light w/alarmdon't forget to `pip install pyserial` or `pip3 install pyserial`"""

import serial
import time

serialPort = 'COM57'  # Change to the serial/COM port of the tower light
baudRate = 9600

RED_ON = 0x11
RED_OFF = 0x21
RED_BLINK = 0x41

YELLOW_ON= 0x12
YELLOW_OFF = 0x22
YELLOW_BLINK = 0x42

GREEN_ON = 0x14
GREEN_OFF = 0x24
GREEN_BLINK = 0x44

BUZZER_ON = 0x18
BUZZER_OFF = 0x28
BUZZER_BLINK = 0x48

def sendCommand(serialport, cmd):
    serialport.write(bytes([cmd]))

if __name__ == '__main__':
    mSerial = serial.Serial(serialPort, baudRate)

    # Clean up any old state
    sendCommand(mSerial, BUZZER_OFF)
    sendCommand(mSerial, RED_OFF)
    sendCommand(mSerial, YELLOW_OFF)
    sendCommand(mSerial, GREEN_OFF)

    # Turn on each LED set in order
    sendCommand(mSerial, RED_ON)
    time.sleep(0.5)

    sendCommand(mSerial, RED_OFF)
    sendCommand(mSerial, YELLOW_ON)
    time.sleep(0.5)

    sendCommand(mSerial, YELLOW_OFF)
    sendCommand(mSerial, GREEN_ON)
    time.sleep(0.5)

    sendCommand(mSerial, GREEN_OFF)

    # Beep!
    sendCommand(mSerial, BUZZER_ON)
    time.sleep(0.1)
    sendCommand(mSerial, BUZZER_OFF)

    # Use the built-in blink modes
    sendCommand(mSerial, RED_BLINK)
    time.sleep(3)
    sendCommand(mSerial, RED_OFF)

    sendCommand(mSerial, YELLOW_BLINK)
    time.sleep(3)
    sendCommand(mSerial, YELLOW_OFF)

    sendCommand(mSerial, GREEN_BLINK)
    time.sleep(3)
    sendCommand(mSerial, GREEN_OFF)

    # Please be kind, rewind!
    sendCommand(mSerial, BUZZER_OFF)
    sendCommand(mSerial, RED_OFF)
    sendCommand(mSerial, YELLOW_OFF)
    sendCommand(mSerial, GREEN_OFF)

    mSerial.close()

Product Weight: 128.0g / 4.5oz
