This gearmotor is a miniature (0.94" x 0.39" x 0.47"), high-power brushed DC motor with 51.45:1 metal gearbox, similar to Sanyo’s popular 12 mm gearmotors. These units have a 0.365"-long, 3 mm-diameter D-shaped output shaft. This version also has a 4.5 x 1 mm extended motor shaft. Key specs at 6 V: 625 RPM and 100 mA free-run, 15 oz-in (1.1 kg-cm) and 1.6 A stall.

This gearmotor is a miniature (0.94" x 0.39" x 0.47"), low-current brushed DC motor with 297.92:1 metal gearbox, similar to Sanyo’s popular 12 mm gearmotors. These units have a 0.365"-long, 3 mm-diameter D-shaped output shaft. This version also has a 4.5 x 1 mm extended motor shaft. Key specs at 6 V: 45 RPM and 30 mA free-run, 40 oz-in (2.9 kg-cm) and 0.36 A stall.

This gearmotor is a miniature (0.94" x 0.39" x 0.47"), high-quality, high-power motor with 9.96:1 metal gearbox, similar to Sanyo’s popular 12 mm gearmotors. These units have a 0.365"-long, 3 mm-diameter D-shaped output shaft. This version also has a 4.5 x 1 mm extended motor shaft. Key specs at 6 V: 3000 RPM and 120 mA free-run, 4 oz-in (0.3 kg-cm) and 1.6 A stall.

This DC gearmotor has an integrated M3*25mm long rod as its output shaft, turn it into a linear actuator. 6V rated voltage, the no-load speed could arrive 98RPM...
