TowerPro SG90C 360 Degree Micro Servo (1.6Kg)

SKU: SER0043

$7.33 AUD, inc GST
$6.66 AUD, exc GST

More Views

TowerPro SG90C 360 Degree Micro Servo (1.6Kg)
7.33 AUD

SKU: SER0043

$7.33 AUD, inc GST
$6.66 AUD, exc GST
In stock, with a short lead time. 94 units dispatch in 3 to 5 days (in addition to the shipping method you choose). Our timing and stock is accurate. Delivery to you by Mon, 23rd of Jul with Express Post within Australia.

Shipping:

  • $6.95 Standard (2-4 days, tracked)
  • $8.95 Express (Overnight*, tracked)
  • $3 Economy Post* (3-7 days, no tracking)
  • FREE Pickup (Newcastle only)

Shipping costs may increase for heavy products or large orders.

Exact shipping can be calculated on the view cart page.

*Conditions apply, see shipping tab below.

Introduction

The TowerPro SG90C is a 360 degree micro servo. It uses a plastic gear drive and is light and compact. It can be used for various applications and DIY products, such as toy cars, boats, windmills etc.

A 360 degree servo’s operation is more similar to a DC motor than a standard servo as only rotation direction and speed can be controlled. There is also no hardware stop inside so that the shaft can rotate freely. Compared to an ordinary DC motor, a 360-degree servo motor does not require additional motor drivers and is plug and play, compact and convenient. Arduino control methods are also the same. When the servo is operating on the 4.8 ~ 6V power supply, the torque can reach 1.2 ~ 1.6Kg x cm




Specification

  • Operating Voltage: 3.5 - 6.0V
  • Supply Voltage: 4.8V ~ 6.0V
  • Dead Zone Width: 5usec
  • Working Speed: 0.12sec/60 (4.8V no load)
  • Stall Torque: 1.2kg/cm (4.8V), 1.6kg/cm (6.0V)
  • Neutral Location: 1500us
  • Interface Description:
  • Brown: GND
  • Red: VCC
  • Orange: S
  • Cable Length: 250mm
  • Operating Temperature: -30°C to + 60°C
  • Dimensions: 22.6 x 12.2 x 30 mm /0.89x0.48x1.18”
  • Weight: 9±1g

  • Parts List

  • TowerPro SG90C 360 Degree Micro Servo (1.6Kg) x1
  • Accessories x1

  • Documentation and Resources:
