Digital Display Ammeter DC 0-50A Blue

SKU: 018-05-AM-50A-BL

$14.50 AUD, inc GST

More Views

Digital Display Ammeter DC 0-50A Blue
14.5 AUD

SKU: 018-05-AM-50A-BL

$14.50 AUD, inc GST
2 reviews 0 5 5
Ships today (delivered by Thu, 26th of Jan)
Shipping Offer

OR

Wide supply voltage operating range; 4.5-28VDC, current sample range is DC 0-50 Amps.

Features:

  • Measuring Range: DC 0-50A with the external 50A/75mV Shunt
  • Error: 1%
  • Display: 0.56" Blue LED Segment Display
  • Refresh Rate: 500mS
  • Power Supply: 4.5-28VDC
  • Current Consumption: 15mA
  • Operating Temperature: -10ºC to 65ºC
  • Dimensions: 48x29x36mm (LxWxD)
  • Hole Size: 46x27mm

Please note that the shunt negative wire and power supply wires must be isolated. Refer to the attached diagram.

Ammeters are susceptible to noise and are not suitable for use in cars or with DC-DC switching supplies. The distance between the panel meter and the shunt must be kept short to assist with stability.

This product is listed in:

Documentation and Resources:
  • What Are NeoPixel LEDs?
  • So in case you haven’t heard yet, digital LEDs are the go-to solution for any project that uses RGB LEDs and you want to avoid the rat's nest that ensures when using multiple RGB LEDs, each colour requiring its own connection. Digital...
  • What Are DotStar LEDs?
  • So in case you haven’t heard yet, digital LEDs are the go-to solution for any project that uses RGB LEDs and you want to avoid the rat's nest that ensures when using multiple RGB LEDs, each colour requiring its own connection. Digitally address...
  • All About LEDs
  • Hello and welcome to our tutorial where we a look at all things LED. Now first of all, what is an LED? LED stands for Light Emitting Diode and is an electronic component used to convert electrical energy to light energy. This process is called electr...

Product Comments

Documentation and Resources:
  • What Are NeoPixel LEDs?
  • So in case you haven’t heard yet, digital LEDs are the go-to solution for any project that uses RGB LEDs and you want to avoid the rat's nest that ensures when using multiple RGB LEDs, each colour requiring its own connection. Digital...
  • What Are DotStar LEDs?
  • So in case you haven’t heard yet, digital LEDs are the go-to solution for any project that uses RGB LEDs and you want to avoid the rat's nest that ensures when using multiple RGB LEDs, each colour requiring its own connection. Digitally address...
  • All About LEDs
  • Hello and welcome to our tutorial where we a look at all things LED. Now first of all, what is an LED? LED stands for Light Emitting Diode and is an electronic component used to convert electrical energy to light energy. This process is called electr...

Customer Reviews

  1. Review by josh - works well verified purchaser
    Rating
    100

    Ordered this ammeter to put on my sons power wheels jeep to give it a cooler feeling. Product is exactly what it says it is. A simple ammeter. Bright even in the sunlight. Wires seem sturdy and long enough for what I was doing.
    Only issue I had was there were no instructions. Had to google the proper way to hook up only because this was my first time messing with an ammeter.
    Good product (Posted on 22/07/2014)

  2. Review by red1jim - good product
    Rating
    100

    It is exactly what I wanted to monitor the amps that is going into the battery on my van that is being generated by my solar panels (Posted on 15/05/2013)
